Engine Piston for 1997-2002 Jeep Wrangler & More - Sealed H822CP

$200.99

Vehicles this part fits

    Part number: H822CP
    UPC: 614046230934
    Condition: New
    Weight: 2.89 LBS
    Pack of 4
    $200.99
    Adding to cart… The item has been added

    Have questions?

    Sealed Power Engine Piston Set P/N:H822CP (Pack of 4)
    Sealed Power Engine Piston Set P/N:H822CP (Pack of 4)
    $200.99
    $200.99

    Sealed H822CP engine piston for the 1997-2002 Jeep Wrangler 4-cylinder 2.5L and other vehicles helps improve cylinder sealing for less blow-by. It is a cast piston with a recessed head.

    • Helps improve cylinder sealing for less blow-by
    • Retains standard ring gaps in the top groove
    • DUROSHIELD® skirt-coated piston
    • Moly-graphite coating extends engine life and reduces friction for higher fuel economy
    • Helps prevent piston damage from inadequate lubrication on start-up

    Quick facts

    • Part: Sealed H822CP engine piston
    • Fits: 1997-2002 Jeep Wrangler 4-cylinder 2.5L and other vehicles
    • Material: Hypereutectic
    • Condition: New

    Loss of compression, oil smoke from the exhaust or an engine knock can mean a piston is worn, though worn piston rings or a worn cylinder bore can be behind the same signs, so find the cause before you replace the pistons.

    Fits

    This engine piston also fits the 1996-2002 Dodge Dakota 4-cylinder 2.5L and the 1996-2000 Jeep Cherokee 4-cylinder 2.5L, and the engine takes four pistons.

    Specifications

    Fit and size

    • Quantity per vehicle: 4
    • Size: not oversized
    • Bore diameter: 3.8750 in
    • Piston pin outside diameter: 0.931 in (23.647 mm)
    • Compression height: 1.592 in
    • Pin offset: 0.06 in (1.524 mm)
    • Ring thickness: top compression 1.50 mm, second compression 1.50 mm, oil 4.00 mm

    Build and materials

    • Piston material: Hypereutectic
    • Skirt: DUROSHIELD® coated
    • Condition: New
    • Country of origin: India

    In the box

    One engine piston set. Assembly lubricant is not included.

    Installation notes

    • Minimum clearance: see the piston fitting information on the carton label.

    Interchange: P3071(4)STD
    P830 · 4798329 · TC3415A · P1122 · 1445P

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    P830, 4798329, TC3415A, P1122, P3071(4)STD, 1445P

    Frequently Asked Questions

    Is the Sealed H822CP engine piston right for a 1997-2002 Jeep Wrangler 4-cylinder 2.5L?

    Yes, Sealed H822CP fits the 1997-2002 Jeep Wrangler 4-cylinder 2.5L, and that engine takes four pistons. If your car is another model, check its year and engine in the "Vehicles it fits" section.

    What bore diameter does this engine piston have?

    Sealed H822CP has a bore diameter of 3.8750 in. Its piston pin outside diameter is 0.931 in (23.647 mm).

    Does this engine piston set include assembly lubricant?

    No. Assembly lubricant is not included with this engine piston set.

    Is the skirt of this Sealed Power engine piston coated?

    Yes, the skirt is DUROSHIELD-coated, and the piston has a moly-graphite coating that reduces friction for higher fuel economy.

    Where do I find the minimum clearance for these pistons?

    See the piston fitting information on the carton label for the minimum clearance of the Sealed H822CP engine pistons.
