Oil Pan for 2010-2011 Honda CR-V - Spectra Premium HOP22A

$237.99
WARNING:California Proposition 65▾

Vehicles this part fits

    Part number: HOP22A
    UPC: 671607015508
    Condition: New
    Weight: 18.52 LBS
    Item Package Quantity: 1
    $237.99
    Adding to cart… The item has been added

    Have questions?

    Spectra Premium Engine Oil Pan P/N:HOP22A
    Spectra Premium Engine Oil Pan P/N:HOP22A
    $237.99
    $237.99

    Spectra Premium HOP22A oil pan for the 2010-2011 Honda CR-V 4-cylinder 2.4L holds the engine oil in the sump at the bottom of the engine. It is built to meet or exceed the performance of the original equipment it replaces.

    • Aluminum body with an uncoated finish
    • Drain plug included, with an M14 - 1.5 drain thread
    • Wet sump with the sump at the center of the pan
    • 18 mounting holes around the pan

    Quick facts

    • Part: Spectra Premium HOP22A oil pan
    • Also called: engine oil pan
    • Fits: 2010-2011 Honda CR-V 4-cylinder 2.4L
    • Material: Aluminum
    • Condition: New

    Oil drips where the car sits, a dented or cracked pan, or oil seeping near the drain plug can mean the pan needs replacing. With the engine off and cool, look for where the oil is actually wet first, since the drain plug or another seal can leak too.

    Fits

    This oil pan is a direct-fit replacement for the 2010-2011 Honda CR-V 4-cylinder 2.4L, which takes one pan.

    Specifications

    Fit and size

    • Quantity per vehicle: 1
    • Mounting holes: 18
    • Maximum width: 323 mm
    • Maximum depth: 148 mm
    • Drain thread size: M14 - 1.5
    • Sump location: Center

    Build and materials

    • Material: Aluminum
    • Finish: Uncoated
    • Sump type: Wet
    • Baffled: No
    • Condition: New
    • Country of origin: China

    In the box

    One oil pan with its drain plug. The oil pickup, windage tray and crankshaft wiper are not included.

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    3312472052216255, 3310203, 264273, 31150399, 11200REZA00, SPIHOP22A, 99658121, NOE99658121, OP37647

    Frequently Asked Questions

    Does the Spectra Premium HOP22A oil pan fit a 2010-2011 Honda CR-V 4-cylinder 2.4L?

    Yes. Spectra Premium HOP22A is a direct-fit replacement for the 2010-2011 Honda CR-V 4-cylinder 2.4L, which takes one pan.

    Is the Spectra Premium engine oil pan made of aluminum?

    Yes. The Spectra Premium HOP22A is aluminum with an uncoated finish. It is a wet-sump pan with the sump at the center.

    Does this Spectra Premium oil pan come with a drain plug?

    Yes, the drain plug is included and has an M14 - 1.5 thread. The oil pickup, windage tray and crankshaft wiper are not included.

    How wide and deep is the HOP22A oil pan?

    The HOP22A oil pan measures 323 mm at its maximum width and 148 mm at its maximum depth, and it has 18 mounting holes.

    What can a damaged oil pan look like?

    Oil drips where the car is parked, a dent or crack in the pan, or seepage near the drain plug can be signs of pan damage. Anything that needs the car lifted is a job for a shop.
