Oil Pan for 2001-2005 Honda Civic & More - Spectra Premium HOP30A

$218.99
WARNING:California Proposition 65▾

Vehicles this part fits

    Part number: HOP30A
    UPC: 671607016536
    Condition: New
    Weight: 10.47 LBS
    Item Package Quantity: 1
    $218.99

    Out of stock

    Have questions?

    Spectra Premium Engine Oil Pan P/N:HOP30A
    Spectra Premium Engine Oil Pan P/N:HOP30A
    $218.99
    $218.99

    Spectra Premium HOP30A oil pan for the 2001-2005 Honda Civic 4-cylinder 1.7L and other vehicles collects and holds the engine's oil at the bottom of the engine. It is a wet sump pan with the sump at the front.

    • Aluminum construction with an uncoated finish
    • Drain plug included, with an M14 - 1.5 drain thread
    • 18 mounting holes
    • Maximum width of 249 mm and maximum depth of 161 mm

    Quick facts

    • Part: Spectra Premium HOP30A oil pan
    • Also called: engine oil pan
    • Fits: 2001-2005 Honda Civic 4-cylinder 1.7L and other vehicles
    • Material: Aluminum
    • Condition: New

    A loose drain plug, a worn drain plug washer or a leaking seal can leave oil in the same spot, so find the cause before replacing the pan. Oil drips under the engine, or a cracked or dented pan, can mean the pan itself needs replacing.

    Fits

    It fits the 2001-2005 Honda Civic 4-cylinder 1.7L and the 2001-2005 Acura EL 4-cylinder 1.7L, and each takes one pan. The pan is made to meet or exceed the performance of the original equipment it replaces.

    Specifications

    Fit and size

    • Quantity per vehicle: 1
    • Sump location: Front
    • Mounting holes: 18
    • Maximum width: 249 mm
    • Maximum depth: 161 mm
    • Drain thread size: M14 - 1.5

    Build and materials

    • Sump type: Wet
    • Material: Aluminum
    • Finish: Uncoated
    • Baffled: No
    • Dipstick port: No
    • Oil level sensor port: No
    • Condition: New
    • Country of origin: China

    In the box

    One oil pan with its drain plug. The oil pump pickup, windage tray and crankshaft wiper are not included.

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    3307350303715620, 3310085, 264486, 31158657, 11200PLE000, SPIHOP30A, OP37608

    Frequently Asked Questions

    Is the Spectra Premium HOP30A the right oil pan for a 2001-2005 Honda Civic 4-cylinder 1.7L?

    Yes. The Spectra Premium HOP30A oil pan fits the 2001-2005 Honda Civic 4-cylinder 1.7L, and the engine takes one pan.

    Does this engine oil pan come with a drain plug?

    Yes, the drain plug is included. The oil pump pickup, windage tray and crankshaft wiper are not part of this listing.

    What drain thread size does the HOP30A oil pan have?

    The HOP30A drain thread is M14 - 1.5. The pan has 18 mounting holes, a maximum width of 249 mm and a maximum depth of 161 mm.

    How can I tell if an aluminum oil pan is cracked or leaking?

    With the engine off and cool, look for oil drips or wet residue under the engine and for cracks or dents in the pan. A shop can pinpoint where a leak starts.

    Is this Spectra Premium oil pan baffled, and does it have a dipstick port?

    No. This Spectra Premium HOP30A pan is not baffled, and it has no dipstick port or oil level sensor port.
