Radiator for 2020-2022 Honda Pilot & More - Spectra Premium CU13402

$229.99
WARNING:California Proposition 65▾

Vehicles this part fits

    Part number: CU13402
    UPC: 671607785517
    Condition: New
    Weight: 43.78 LBS
    Item Package Quantity: 1
    $229.99
    Adding to cart… The item has been added

    Have questions?

    Spectra Premium Radiator P/N:CU13402
    Spectra Premium Radiator P/N:CU13402
    $229.99
    $229.99

    Spectra Premium CU13402 radiator for the 2020-2022 Honda Pilot V6 3.5L and other vehicles moves heat out of the engine coolant through its aluminum core. Its structure and design are built to carry the same durability expectations as the OE radiator.

    • Aluminum core with plastic tanks
    • One-row down-flow core with the inlet at the top left and the outlet at the bottom left
    • Post mounting type
    • No built-in engine or transmission oil cooler

    Quick facts

    • Part: Spectra Premium CU13402 radiator
    • Fits: 2020-2022 Honda Pilot V6 3.5L and other vehicles
    • Material: Aluminum core, plastic tanks
    • Condition: New

    Coolant leaks at the core or tanks, steady coolant loss or an engine that runs hot can mean the radiator is wearing out. A stuck thermostat can also run an engine hot, so these signs alone do not prove the radiator is at fault.

    Fits

    Listed for several Honda and Acura models, including a radiator for the 2019-2026 Honda Passport V6 3.5L and a radiator for the 2017-2026 Honda Ridgeline V6 3.5L. The 2020-2022 Honda Pilot V6 3.5L takes one radiator, and this listing is one. To check your exact model and engine, open the "Vehicles it fits" section.

    Specifications

    Fit and size

    • Quantity per vehicle: 1
    • Core height: 19.6875 in
    • Core width: 30.1875 in
    • Core thickness: 1.0625 in
    • Inlet diameter: 1.25 in
    • Outlet diameter: 1.25 in
    • Inlet header: 31.3125 in long, 2 in wide
    • Outlet header: 31.3125 in long, 2 in wide
    • Inlet location: top left
    • Outlet location: bottom left
    • Mounting type: post

    Build and materials

    • Core material: aluminum
    • Tank material: plastic
    • Core rows: 1
    • Flow type: down flow
    • Condition: new
    • Country of origin: Indonesia

    In the box

    One radiator. A frame, an engine oil cooler and a transmission oil cooler are not included.

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    103831, 10182345256654418, 8013402, 190105J6A01, 13402, 3644, C13402, 0AHD6476, 2219337, 13402C, 190105JA01, RAD13402, A13402, 606314, CR13402, 13402DPI, AC3010153, 2237, 4113402, RA13402C

    Frequently Asked Questions

    Is this the right Honda Pilot radiator for a 2020-2022 V6 3.5L?

    Yes. Spectra Premium CU13402 is listed for the 2020-2022 Honda Pilot V6 3.5L. For other models and engines, open the "Vehicles it fits" section.

    What are the core and tank materials on the Spectra Premium CU13402 radiator?

    The core is aluminum and the tanks are plastic. The core is one row, 30.1875 in wide by 19.6875 in high and 1.0625 in thick.

    Does this radiator come with a frame or an oil cooler?

    No. This radiator is sold alone, with no frame, engine oil cooler or transmission oil cooler included, and it has no internal oil cooler.

    What size are the inlet and outlet connections on this radiator?

    Both are 1.25 in in diameter. The inlet sits at the top left and the outlet at the bottom left, in a down-flow layout.

    How can I tell if my radiator is leaking and needs replacing?

    Coolant stains, cracks or damp spots on the core or plastic tanks, looked at with the engine cool, can mean the radiator is failing. A shop can pressure-test the cooling system.
