Front Differential Ring and Pinion for 2007-2022 Jeep Wrangler & More - Dana/Spicer 10026639

$423.99
WARNING:California Proposition 65▾

Vehicles this part fits

    Part number: 10026639
    UPC: 023913495336
    Condition: New
    Weight: 24.50 LBS
    Item Package Quantity: 1
    $423.99
    Adding to cart… The item has been added

    Have questions?

    Spicer Differential Ring and Pinion P/N:10026639
    Spicer Differential Ring and Pinion P/N:10026639
    $423.99
    $423.99

    Dana/Spicer 10026639 front differential ring and pinion for the 2007-2022 Jeep Wrangler and other vehicles transfers driveshaft torque to the front axle shafts. It is built for the Dana 30 front axle.

    • 4.88 gear ratio for the Dana 30 front axle
    • Hobbed and shaved gearing for optimal mating, to minimize stress and maximize life
    • Precision heat-treating and shot-peening reduce residual stress and double the fatigue life of the gear
    • High-grade steel for maximum durability
    • Metallurgy chosen for consistent product quality

    Quick facts

    • Part: Dana/Spicer 10026639 differential ring and pinion
    • Fits: 2007-2022 Jeep Wrangler and other vehicles
    • Position: Front
    • Material: High-grade steel
    • Condition: New

    A whine or howl from the front axle that changes with speed, or a clunk when the load shifts between drive and coast, can mean the gears are worn. These signs alone do not prove the ring and pinion is the problem, since a worn axle bearing can make similar noise.

    Fits

    This ring and pinion fits the 2007-2022 Jeep Wrangler and the 2018 Jeep Wrangler JK, and each takes one set.

    Specifications

    Fit and size

    • Position: Front
    • Axle model: Dana 30 front
    • Gear ratio: 4.88
    • Quantity per vehicle: 1

    Build and materials

    • Material: High-grade steel
    • Condition: New
    • Country of origin: United States

    Product information is for general reference and may contain errors. See our Disclaimer.

    Frequently Asked Questions

    Is the Dana/Spicer 10026639 ring and pinion right for a 2018 Jeep Wrangler JK?

    Yes. Dana/Spicer 10026639 fits the 2018 Jeep Wrangler JK and the 2007-2022 Jeep Wrangler, for the Dana 30 front axle.

    What gear ratio is this front ring and pinion?

    The ratio is 4.88. Dana/Spicer 10026639 is made for the front position of a Dana 30 axle.

    What is this Spicer ring and pinion made of?

    High-grade steel. Precision heat-treating and shot-peening are used to reduce residual stress in the gears.

    How can I tell if the gears in a front differential are wearing out?

    A whine or howl from the front axle that changes with speed can be a sign of gear wear. A shop can open the differential and inspect the ring and pinion.

    What does hobbed and shaved gearing do on this ring and pinion?

    On this ring and pinion, hobbed and shaved gearing gives optimal mating between the gears, which minimizes stress and maximizes gear life.
