Front Drive Axle Shaft Universal Joint for 2006-2009 Dodge Ram 1500 & More - DANA SPICER CHASSIS 5006813

$120.99
WARNING:California Proposition 65▾

Vehicles this part fits

    Part number: 5006813
    UPC: 023913121204
    Condition: New
    Weight: 2.60 LBS
    Item Package Quantity: 1
    $120.99
    Adding to cart… The item has been added

    Have questions?

    Spicer Drive Axle Shaft Universal Joint P/N:5006813
    Spicer Drive Axle Shaft Universal Joint P/N:5006813
    $120.99
    $120.99

    DANA SPICER CHASSIS 5006813 front drive axle shaft universal joint for the 2006-2009 Dodge Ram 1500 and other vehicles carries drive torque through the axle shaft while the angle changes at the wheel end.

    • Journal cross with a solid cold-formed body for wear resistance and strength
    • Bearing cups heat treated for strength, precision-ground and case-hardened for durability
    • Multi-lip seal keeps grease in and contaminants out across a wider range of environments
    • Thrust washers prevent metal-to-metal contact and wear, and lower the overall operating temperature
    • Non-greaseable ISR style with round bearing caps and internal snap rings

    Quick facts

    • Part: DANA SPICER CHASSIS 5006813 drive axle shaft universal joint
    • Fits: 2006-2009 Dodge Ram 1500 and other vehicles
    • Position: Front axle at wheels
    • Material: Steel
    • Condition: New

    A worn joint can show up as vibration, a clunk when you get on or off the throttle, or grease and rust dust around the seals. These signs alone do not prove the joint is at fault, since a worn wheel bearing can make similar noise. Do the front joints as a pair, with this listing covering one.

    Fits

    This universal joint is a direct-fit replacement for the 2006-2009 Dodge Ram 1500, the 2003-2010 Dodge Ram 2500 and the 2003-2009 Dodge Ram 3500.

    Specifications

    Fit and size

    • Position: Front axle at wheels
    • Quantity per vehicle: 2
    • Series: AAM 1485WJ
    • Bearing cap diameter: 1.375 in (34.925 mm)
    • Length A and B: 2.92 in (74.2 mm) each
    • Snap ring type: Internal

    Build and materials

    • Type: ISR style, non-greaseable
    • Material: Steel
    • Bearing cap type: Round with ISR groove
    • Bearing cap finish: Ground
    • Seal material: Rubber
    • Coating: None
    • Condition: New
    • Country of origin: United States

    In the box

    One universal joint with its snap rings. The front axle takes two joints in total. Mounting hardware is not included, so plan on new fasteners where the job needs them.

    Product information is for general reference and may contain errors. See our Disclaimer.

    Frequently Asked Questions

    Does the DANA SPICER CHASSIS 5006813 fit a 2003-2010 Dodge Ram 2500?

    Yes. DANA SPICER CHASSIS 5006813 is listed for the 2003-2010 Dodge Ram 2500 with any engine, and this listing is one joint.

    Is the DANA SPICER CHASSIS drive axle shaft universal joint greaseable?

    No. This joint is non-greaseable, so it has no grease zerk and does not need one.

    Are snap rings included with this front drive axle shaft universal joint?

    Yes, the snap rings come with the joint and are the internal type. Mounting hardware is not included.

    What size are the bearing caps on this universal joint?

    The bearing caps on DANA SPICER CHASSIS 5006813 are 1.375 in (34.925 mm) in diameter, round with an ISR groove. The joint is 2.92 in (74.2 mm) long.

    What can a worn front axle shaft universal joint feel or sound like?

    It can show as vibration, a clunk when you get on or off the throttle, or grease and rust dust at the seals. Have a shop look at it promptly rather than driving on it.
