Mevotech Supreme Suspension Control Arm and Ball Joint Assembly P/N:CMS861240
Mevotech Supreme CMS501132 rear right upper control arm with ball joint for the 2008-2015 Cadillac CTS and other vehicles holds the wheel in position while the suspension moves. This Mevotech Supreme control arm is also called a control arm and ball joint assembly, and it comes with its rubber bushings.
A worn arm can show up as a clunk over bumps, uneven tire wear or a loose feel from the rear, though worn parts nearby can feel much the same. With the engine off, look at the rear tires for uneven wear, and have a shop check the bushings and ball joint for play, before you replace the arm. Rear upper arms are normally replaced as a pair; this listing is one arm for the rear right, and the rear left is a separate part. The rear axle takes one upper arm per side.
It is a direct-fit replacement for the 2008-2015 Cadillac CTS, the 2005-2011 Cadillac STS and the 2004-2009 Cadillac SRX.
Fit and size
Build and materials
One control arm with ball joint and bushings, plus a part-specific nylon locking nut.
Interchange: 522-488
19327294 · QGS501132 · 25766118 · TC7368 · CB90538 · CB90538PR · CA12636 · 15267620 · 25716354 · RK622101 · C6GS501132 · GS501132 · 2607514 · 1231105 · 30034582 · 5CB50387 · X06CA0303 · TK622101
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
Is this a 2008-2015 Cadillac CTS control arm for the rear right upper position?
Yes. Mevotech Supreme CMS501132 is the rear right upper arm for the 2008-2015 Cadillac CTS. It also fits the 2005-2011 Cadillac STS and the 2004-2009 Cadillac SRX.
Does the Mevotech Supreme suspension control arm come with a locking nut?
Yes. It comes with a part-specific nylon locking nut for the ball joint, plus the ball joint and rubber bushings that go with the arm.
What is the CMS501132 arm made of, and is the ball joint greased?
The CMS501132 arm is aluminum and its bushings are rubber. The ball joint is pre-greased, with a press-in mount and a threaded stud.
How can I tell if a rear upper control arm is wearing out?
A clunk over bumps, uneven tire wear or a loose feel from the rear can come from a worn arm or ball joint, though other parts can cause them too. A shop can check ball joint play.
How long and wide is this rear right upper control arm?
Mevotech Supreme CMS501132 has a maximum length of 16.5 in and a maximum width of 13.95 in.
