Front Right Lower Control Arm with Ball Joint for 2006-2012 Kia Sedona & More - Mevotech Supreme CMS901038

$129.99

Vehicles this part fits

    Part number: CMS901038
    UPC: 669719074193
    Condition: New
    Weight: 29.15 LBS
    Item Package Quantity: 1
    $129.99
    Adding to cart… The item has been added

    Have questions?

    Mevotech Supreme Suspension Control Arm and Ball Joint Assembly P/N:CMS901038
    Mevotech Supreme Suspension Control Arm and Ball Joint Assembly P/N:CMS901038
    $129.99
    $129.99

    Mevotech Supreme CMS901038 front right lower control arm with ball joint for the 2006-2012 Kia Sedona and other vehicles links the wheel to the chassis. It includes the ball joint, rubber bushings and a neoprene dust boot.

    • Part of the Mevotech Supreme line, engineered in-house with application-specific upgrades
    • Sintered bearings for longer-lasting performance
    • 180 degree SAE grease fitting included for servicing
    • Application-specific pinch bolt and locking nut provided with the ball joint
    • Stamped steel construction with a protective surface treatment against rust

    Quick facts

    • Part: Mevotech Supreme CMS901038 control arm with ball joint
    • Also called: control arm and ball joint assembly
    • Fits: 2006-2012 Kia Sedona and other vehicles
    • Position: Front right lower
    • Material: Steel
    • Condition: New

    A worn ball joint or bushing can show up as a clunk over bumps, uneven tire wear or loose steering feel. A worn sway bar link, strut mount or tie rod end can be behind these signs too, so find the cause before buying. If a worn control arm and ball joint assembly is the cause, this one replaces it.

    Fits

    It is a direct-fit replacement for the 2006-2012 and 2014 Kia Sedona and the 2007-2010 Hyundai Entourage. On the 2006-2012 Kia Sedona, this listing is the one front right lower arm; the front left is a separate part ordered separately, and both sides are normally replaced together.

    Specifications

    Fit and size

    • Position: front right lower
    • Quantity per application: 1
    • Maximum width: 21.75 in
    • Maximum length: 15.75 in
    • Ball joint mounting type: bolt in
    • Ball joint stud type: grooved

    Build and materials

    • Control arm material: steel
    • Bushing material: rubber
    • Bearing material: sintered metal
    • Dust boot material: neoprene
    • Pre-greased and greaseable, with grease fitting included
    • Condition: new
    • Country of origin: China

    In the box

    One control arm with ball joint, bushings, dust boot, a 180 degree SAE grease fitting, and an application-specific pinch bolt and locking nut.

    Installation notes

    • Arrives pre-greased.
    • Labor Saver designs, tools and hardware make installation faster and easier.

    Interchange: 101-6111 · 102-6111 · 622.50829 · 521-736
    19337684 · TC5753 · CB63234 · CB63234PR · CA16348 · 545014D101 · 545014D100 · 545014D102 · RK622266 · 30030317 · X23CA7455 · X23CJ7030 · TK622266

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    19337684, 101-6111, 102-6111, 622.50829, TC5753, 521-736, CB63234, CB63234PR, CA16348, 545014D101, 545014D100, 545014D102, RK622266, CMS901038, 30030317, X23CA7455, X23CJ7030, TK622266

    Frequently Asked Questions

    Is this a 2006-2012 Kia Sedona control arm for the front right side?

    Yes. Mevotech Supreme CMS901038 is a front right lower control arm with ball joint for the 2006-2012 Kia Sedona. The front left side is a separate part.

    What comes with this Mevotech Supreme lower control arm?

    Mevotech Supreme CMS901038 includes the ball joint, rubber bushings, neoprene dust boot, a 180 degree SAE grease fitting and an application-specific pinch bolt and locking nut.

    Is the Mevotech Supreme control arm made of steel?

    Yes. The arm is steel with stamped steel construction and a protective surface treatment. The bushings are rubber and the bearing material is sintered metal.

    What are signs a Mevotech Supreme suspension control arm ball joint is worn?

    A clunk over bumps, uneven tire wear or loose steering can mean the joint is worn. With the engine off, a torn dust boot or cracked rubber bushings are visible signs; a shop can test the rest.

    Can I grease the ball joint on this control arm?

    Yes. The ball joint is pre-greased and greaseable, and a 180 degree SAE grease fitting is included for servicing.
