Four Seasons 97310 A/C compressor for the 2004-2007 Toyota Sienna pumps and pressurizes refrigerant to run the air conditioning system. This remanufactured Four Seasons ac compressor is 100 percent tested so its function and noise level meet or exceed OE specifications.
- Individually vacuum and pressure tested to check for leaks
- Clutch included, with a 12 V DC coil
- Six-groove pulley with a 4.750 in outside diameter for a serpentine belt
- Tangent mount with a pin connector
Quick facts
- Part: Four Seasons 97310 A/C compressor
- Fits: 2004-2007 Toyota Sienna
- Condition: Remanufactured
Warm air from the vents, a rattling or grinding noise from the compressor, or a clutch that stays disengaged can mean the compressor is worn, though a faulty A/C relay or pressure switch can be behind the same signs.
Fits
This is a 2004-2007 Toyota Sienna A/C compressor, a direct-fit replacement that takes one per vehicle.
Specifications
Fit and size
- Quantity per vehicle: 1
- Pulley outside diameter: 4.750 in
- Pulley grooves: 6
- Mounting type: Tangent mount
- Outlet C length: 119 mm
- Coil voltage: 12 V DC
Build and materials
- Condition: Remanufactured
- Compressor type: Denso 10S20C
- Refrigerant type: R134A
- Compatible refrigerant oil: PAG 46
- Pulley belt type: Serpentine
- Clutch: Included
- Connector type: Pin
- Country of origin: Mexico
In the box
One remanufactured A/C compressor with its clutch, one O-ring 24681 and one O-ring 24661. Mounting hardware and the switch are not included, so plan on new fasteners, since the old ones may not be reusable.
Installation notes
- The compressor is pre-charged with 3 ounces of PAG oil for R134a or R1234yf applications.
- May require use of the OE manifold.
Interchange: 255485 · DW97310 · 11197310 · 5512103 · A55485 · 2011282R · 140135C · 034958 · 883100803184 · 8831008031DS · 8832008050 · 8832008051 · CO10854RE
This part cross-references / interchanges with the following part numbers:
255485, DW97310, 11197310, 97310, 5512103, A55485, 2011282R, 140135C, 034958, 883100803184, 8831008031DS, 8832008050, 8832008051, CO10854RE
Frequently Asked Questions
Is this a Toyota Sienna A/C compressor replacement for the 2004-2007 model years?
Yes. Four Seasons 97310 is a direct-fit replacement A/C compressor for the 2004-2007 Toyota Sienna, and each vehicle takes one.
Does the Four Seasons compressor come with O-rings and a clutch?
Yes. The Four Seasons 97310 includes the clutch plus one O-ring 24681 and one O-ring 24661. Mounting hardware and the switch are not included.
Is oil already in this remanufactured compressor?
Yes. This compressor comes with 3 ounces of PAG oil already in it, for R134a or R1234yf systems, and PAG 46 is the compatible refrigerant oil type.
How many grooves does the pulley on this compressor have?
The pulley has 6 grooves for a serpentine belt and a 4.750 in outside diameter. The clutch coil runs on 12 V DC.
Is this remanufactured compressor tested for leaks?
Yes. Four Seasons 97310 is individually vacuum and pressure tested to check for leaks, and tested for compressor function and noise level.
