Four Seasons 198392 A/C compressor for the 2013-2018 Ford Focus and other vehicles compresses refrigerant and circulates it through the air conditioning system. It is a new unit and comes with its clutch.
- Works with R134a or R1234yf refrigerant systems
- Individually vacuum, pressure and helium mass spectrometer tested for leaks
- Validated to deliver performance equivalent to 100,000 miles
- Clutch with a 4-groove pulley for the serpentine belt
Quick facts
- Part: Four Seasons 198392 A/C compressor
- Fits: 2013-2018 Ford Focus and other vehicles
- Condition: New
Warm air from the vents, a noisy or seized clutch, or oily residue around the compressor can mean it is wearing out. The same signs can come from other A/C parts, so with the engine off, look over the clutch and fittings for oil residue or damage first, and leave pressure testing to a shop.
Fits
This is an A/C compressor for the 2017-2019 Ford Escape and the 2013-2018 Ford Focus, and each takes one. The compressor meets or exceeds OE specifications.
Specifications
Fit and size
- Quantity per vehicle: 1
- Outside pulley diameter: 4.250 in
- Pulley grooves: 4
- Mounting type: 3 Tangent One on Rear Head
- Coil voltage: 12 V DC
- Connector type: Pin
Build and materials
- Condition: New
- Compressor: Halla HCC-VS16
- Clutch: included
- Pulley belt type: Serpentine
- Refrigerant: R134a or R1234yf
- Compatible refrigerant oil type: PAG 46
- Country of origin: Mexico
In the box
One A/C compressor with its clutch and the O-rings and sealing washers needed to install it. Mounting hardware and a switch are not included; plan on new bolts, since the old ones may not be reusable.
Installation notes
- Pre-charged with 3 ounces of PAG oil, which reduces install time and simplifies the job.
Interchange: C2759 · C3251 · C3524 · 276334 · T198392 · 639993 · CV6Z19703H · CV6Z19703N · GV6Z19703S · GV6Z19703U · 207670 · AC1207670 · YCC359 · YCC389 · YCC412 · A76334 · 141208NC · 141352FD · CO11410C · CO11410Z
This part cross-references / interchanges with the following part numbers:
C2759, C3251, C3524, 276334, T198392, 639993, 198392, CV6Z19703H, CV6Z19703N, GV6Z19703S, GV6Z19703U, 207670, AC1207670, YCC359, YCC389, YCC412, A76334, 141208NC, 141352FD, CO11410C, CO11410Z
Frequently Asked Questions
Is Four Seasons 198392 a 2015 Ford Focus AC compressor (2013-2018 Ford Focus)?
Yes. Four Seasons 198392 fits the 2013-2018 Ford Focus, which includes 2015, and the 2017-2019 Ford Escape, and each takes one.
Is this Four Seasons AC compressor pre-charged with oil?
Yes. Four Seasons 198392 comes pre-charged with 3 ounces of PAG oil, and PAG 46 is its compatible refrigerant oil type.
Does the Four Seasons compressor work with R1234yf systems?
Yes. This A/C compressor works with R134a or R1234yf systems.
Does the compressor come with O-rings, and what is left out?
Yes. It comes with its clutch and the O-rings and sealing washers needed to install it; mounting hardware and a switch are not included.
How many grooves does the pulley on this A/C compressor have?
The pulley has 4 grooves for a serpentine belt and measures 4.250 in across the outside.
