Four Seasons 98315 A/C compressor for the 2012-2017 Toyota Camry and other vehicles compresses and circulates refrigerant in the A/C system. This new Four Seasons ac compressor is a Denso TSB19C unit with the clutch included, built to OE-level specifications.
- Validated for performance equivalent to 100,000 miles of use
- Each compressor is vacuum, pressure and helium mass spectrometer tested individually for leaks
- Operates in R134a or R1234yf refrigerant systems
- Clutch included, with a serpentine-belt pulley
Quick facts
- Part: Four Seasons 98315 A/C compressor
- Fits: the 2012-2017 Toyota Camry and other vehicles
- Condition: New
Warm air from the vents, a noisy compressor or a clutch that no longer engages can mean the compressor is worn, though a refrigerant leak or a faulty clutch relay can be behind them as well, so find the cause before you replace it.
Fits
The vehicles it fits include the 2012-2017 Toyota Camry, the 2011-2016 Toyota Sienna and the 2011-2013 Toyota Highlander, each taking one compressor. A 2014 Toyota Camry ac compressor is covered too, since 2014 sits inside those Camry years. If your car is not named here, look it up in the "Vehicles it fits" section to see whether this one is listed for it.
Specifications
Fit and size
- Quantity per vehicle: 1
- Mounting type: Tangent mount
- Outside pulley diameter: 4.500 in
- Pulley grooves: 7
- Outlet length: 115 mm
- Coil voltage: 12 V DC
- ECV harness connector: compressor SE10F, vehicle SE10M
- Connector type: Pin
Build and materials
- Compressor type: Denso TSB19C
- Clutch: included
- Pulley belt type: Serpentine
- Refrigerant: R134a or R1234yf systems
- Compatible oil type: PAG 46
- Condition: New
- Country of origin: Mexico
In the box
One compressor with its clutch, O-ring 24681, O-ring 24661 and the sealing washers needed to install it. Mounting hardware and a switch are not included, so plan on new bolts.
Installation notes
- Arrives pre-charged with 3 ounces of PAG oil, which reduces install time.
- The compressor's ECV harness connector is SE10F and mates with the vehicle's SE10M.
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Is this the right 2012-2017 Toyota Camry ac compressor for my car?
Yes. Four Seasons 98315 is listed for the 2012-2017 Toyota Camry, and the car takes one compressor.
Will the same part work as a 2011-2016 Toyota Sienna ac compressor?
Yes. The 2011-2016 Toyota Sienna is listed for Four Seasons 98315 as well, with one compressor per vehicle.
Which O-rings come with the Four Seasons compressor?
Two O-rings, numbers 24681 and 24661, and the sealing washers come with it. Mounting hardware and a switch are not included, so plan on new bolts.
What oil and refrigerant does this A/C compressor use?
It comes pre-charged with 3 ounces of PAG oil, and PAG 46 is the compatible oil type. It works with R134a or R1234yf systems.
What size is the pulley on this A/C compressor?
The pulley has 7 grooves, measures 4.500 inches across the outside and takes a serpentine belt.
