Four Seasons 83903 A/C condenser and receiver drier assembly for the 2006-2011 Chevrolet HHR cools hot refrigerant so it turns back into a liquid. This Four Seasons condenser replaces a leaking or damaged one in the air conditioning system.
- Parallel flow core made of aluminum
- Filter drier included in the assembly
- Block fittings on both the inlet and the outlet
- Ribbed brackets add strength and rigidity for mounting and component support
Quick facts
- Part: Four Seasons 83903 A/C condenser and receiver drier assembly
- Fits: 2006-2011 Chevrolet HHR
- Material: Aluminum
- Condition: New
Weak cooling, oily residue on the condenser or its fittings, or a core damaged by road debris can mean the condenser needs replacing. These signs alone do not prove this part is the problem, since a low refrigerant charge is another common cause.
Fits
This assembly is a direct-fit replacement for the 2006-2011 Chevrolet HHR. It meets or exceeds OE specifications, and its tube design matches the original condenser. The 2006-2011 Chevrolet HHR takes one.
Specifications
Fit and size
- Quantity per vehicle: 1
- Core width: 20-5/8 in
- Core length: 15-3/4 in
- Inlet type: block fitting
- Outlet type: block fitting
- Refrigerant type: R12, R134a, R1234YF
Build and materials
- Material: aluminum
- Condenser core type: parallel flow
- Filter drier: included
- Condition: new
- Country of origin: China
In the box
One A/C condenser and receiver drier assembly with its filter drier, plus one O-ring A (24402) and one O-ring B (24401), both slim line sealing washers. Mounting hardware is not included, so plan on new hardware rather than reusing the old pieces.
Interchange: 7013462 · 408963 · 745018 · 11183903 · 3462 · 908963 · 15834081 · 20889194 · 22727324 · 708968 · 3462C · 1AMAC83903 · A87903 · 4770840 · 2462190 · 2173 · 73462 · T83903 · CN3462PFC
This part cross-references / interchanges with the following part numbers:
7013462, 408963, 745018, 11183903, 83903, 3462, 908963, 15834081, 20889194, 22727324, 708968, 3462C, 1AMAC83903, A87903, 4770840, 2462190, 2173, 73462, T83903, CN3462PFC
Frequently Asked Questions
Is this Four Seasons AC condenser a fit for the 2006-2011 Chevrolet HHR?
Yes. Four Seasons 83903 fits the 2006-2011 Chevrolet HHR, which takes one.
Does the Four Seasons 83903 come with the filter drier and O-rings?
Yes. Four Seasons 83903 includes the filter drier in the assembly, plus one O-ring A (24402) and one O-ring B (24401). Mounting hardware is not included.
What kind of core and fittings does this condenser have?
This condenser has a parallel flow aluminum core with block fittings on the inlet and outlet. The core measures 20-5/8 in wide by 15-3/4 in long.
What can a leaking aluminum condenser look like?
Oily residue on the condenser or its fittings, bent fins or road-debris damage, and weak cooling can all point to a condenser problem. A shop can leak-test the A/C system.
Does the Four Seasons 83903 replace number 15834081?
Yes. Number 15834081 is on the interchange list for Four Seasons 83903, so it is one of the numbers this assembly replaces.
