Four Seasons 56382 A/C manifold hose for the 1999-2004 Ford Mustang V6 3.8L and the 2004 Mustang V6 3.9L carries refrigerant on the discharge and suction sides of the A/C system. This AC manifold hose assembly is a discharge and suction line, sold individually.
- Gaskets, o-rings and seals included with the assembly
- Double wall barrier hose for R1234YF, R134A or R12 refrigerant
- Crimp fitting connection
- Muffler and service port on the assembly
- Application specific design
Quick facts
- Part: Four Seasons 56382 A/C manifold hose
- Also called: AC manifold hose assembly
- Fits: the 1999-2004 Ford Mustang V6 3.8L and the 2004 Mustang V6 3.9L
- Material: Aluminum and rubber
- Condition: New
Weak cooling or oily residue around the hose and its fittings can point to a refrigerant leak, though other A/C faults also weaken cooling. If a leaking or damaged hose is the cause, this assembly replaces it. As a first check, look the hose over for cracks, chafed spots and residue with the engine off and cool; opening or leak-testing the A/C system is a shop job.
Fits
This is a direct-fit replacement for the 1999-2004 Ford Mustang V6 3.8L and the 2004 Mustang V6 3.9L, and each takes one.
Specifications
Fit and size
- Quantity per vehicle: 1
- Suction end style: male springlock
- Discharge end style: P-nut fitting
- Refrigerant type: R134A
Build and materials
- Type: discharge and suction line
- Material: aluminum and rubber
- Condition: new
- Country of origin: China
In the box
One hose assembly with a muffler and a service port, plus one 24606 O-ring, one 24628 O-ring, three 24670 O-rings and one 24220 spring. A bracket and separate fittings are not included, and old brackets or fittings may not be reusable, so plan on new ones.
Frequently Asked Questions
Is the Four Seasons 56382 A/C manifold hose right for the 1999-2004 Ford Mustang V6 3.8L?
Yes. Four Seasons 56382 fits the 1999-2004 Ford Mustang V6 3.8L and the 2004 Mustang V6 3.9L, and each takes one.
Does the Four Seasons 56382 hose assembly come with O-rings?
Yes. Four Seasons 56382 includes one 24606 O-ring, one 24628 O-ring, three 24670 O-rings and a 24220 spring. A bracket and separate fittings are not included.
Which refrigerants can this hose assembly be used with?
The double wall barrier hose is compatible with R1234YF, R134A or R12. The listed refrigerant type for this assembly is R134A.
What end styles does this discharge and suction hose have?
The suction end is a male springlock and the discharge end is a P-nut fitting. The hose uses a crimp fitting connection.
Does this hose assembly include a muffler or service port?
Yes. The assembly comes with a muffler and a service port. It does not include a bracket.
