Arnott Industries SK-3600 front left strut assembly for the 2013-2016 Lincoln MKZ replaces the strut and coil spring as one pre-assembled unit. Also called a complete strut and coil spring assembly, it works without external commands from the vehicle.
- Pre-assembled strut and coil spring unit for convenient installation
- Converts active to passive with electronic-to-passive shock technology
- Custom-valved shock adapted to driving style
- Twin-tube hydraulic damper that is gas charged
- Improved seals to prevent leaks
Quick facts
- Part: Arnott Industries SK-3600 strut assembly
- Also called: complete strut and coil spring assembly
- Fits: 2013-2016 Lincoln MKZ
- Position: Front left
- Material: Steel
- Condition: New
The passive design delivers the stability, handling, control and comfort of the original OE strut, and Arnott engineers tested the internal strut settings to mimic OE performance. A leaking strut body, a bouncy ride or a clunk over bumps can be signs of wear. Worn sway bar links, control arm bushings or tires can be behind these signs too, so find the cause before buying a strut.
Fits
It fits the 2013-2016 Lincoln MKZ, with one strut on each side of the front axle. This listing is the front left strut; the front right is a separate part, and the pair on that axle is normally done together.
Specifications
Fit and size
- Position: front left
- Quantity per application: 1
- Body and outer housing diameter: 55 mm
- Upper mount type: bolt
- Lower mount type: bracket
Build and materials
- Housing material: steel
- Dust shield material: rubber
- Spring rate: linear
- Suspension type: passive
- Condition: new
In the box
One front left strut assembly with coil spring, spring seat, spring isolators, bearing plate, upper mounting isolator, dust shield, boot and mounting hardware. The mounting bracket and lower mounting isolator are not included.
Interchange: DG9Z18124B · DG9Z18124V · EG9Z18124B · EG9Z18124D · EG9Z18124K
This part cross-references / interchanges with the following part numbers:
DG9Z18124B, DG9Z18124V, EG9Z18124B, EG9Z18124D, EG9Z18124K
Frequently Asked Questions
Is the Arnott Industries SK-3600 strut assembly right for the 2013-2016 Lincoln MKZ?
Yes. The Arnott Industries SK-3600 is a front left strut assembly for the 2013-2016 Lincoln MKZ. The front right side is a separate part.
Does the SK-3600 strut assembly come with the coil spring and mounting hardware?
Yes. The Arnott Industries SK-3600 comes with the coil spring, spring seat, bearing plate, isolators, dust shield, boot and mounting hardware. The mounting bracket and lower mounting isolator are not included.
Is this front left strut assembly active or passive?
It is passive. The design works without external commands from the vehicle and converts active to passive operation.
How can I tell if this front left strut assembly is wearing out?
With the engine off, look at the strut body for oily wetness. A bouncy ride or a clunk over bumps can also be signs of wear, and a shop can confirm it.
Is EG9Z18124B a cross-reference for the Arnott SK-3600 strut?
Yes. EG9Z18124B is one of the numbers on the Interchange line for the Arnott Industries SK-3600 front left strut assembly.
