Bosch 25010587 front brake rotor for the 1996-2002 Chevrolet Express 2500 and other vehicles turns brake pad pressure into stopping force at the front wheels. This Bosch QuietCast premium disc brake rotor comes from a line checked with 3D laser measuring and repeated inspection.
- 100% precision balanced for smooth operation and minimal vibration
- Tight tolerances with low run-out and DTV specifications for a smooth pedal feel without pulsation
- Heat-flowed castings promote consistent wear for quiet operation and long life
- Vented design with a vane configuration for proper heat dissipation from the braking system
- Full coating, including the vanes where applicable, to protect against corrosion
- Edge code engraved at the factory carries the part identification and discard specification
Quick facts
- Part: Bosch 25010587 brake rotor
- Also called: disc brake rotor
- Fits: 1996-2002 Chevrolet Express 2500 and other vehicles
- Position: Front
- Material: Iron alloy
- Condition: New
A pulsing brake pedal, a steering wheel that shakes when you stop, or deep grooves on the braking surface can mean the rotor is warped or worn, and a rotor worn past its discard thickness is due for replacement. Before you replace it, rule out worn pads, a sticking caliper or loose wheel bearings, since any of them can bring on similar pulsation or noise.
Fits
Vehicles it fits include the 1996-2002 Chevrolet Express 2500 and the 1996-2002 GMC Savana 2500, and it is a direct-fit replacement for a wide range of Chevrolet and GMC trucks and vans. Because this listing is a single rotor, the rotor on the other side of the front axle is normally replaced at the same time. If your truck or van is not named here, open the "Vehicles it fits" section to check your exact model and engine.
Specifications
Fit and size
- Position: Front
- Quantity per vehicle: 2
- Outside diameter: 294.7 mm
- Center bore diameter: 65.011 mm
- Bolt circle: 139.7 mm, 6 bolt holes
- Nominal thickness: 32.6 mm
- Discard thickness: 30.86 mm
- Overall height: 114.5 mm
Build and materials
- Construction: Vented, conventional rotor
- Braking surface: Directional, smooth
- Material: Iron alloy
- Disc finish: Geomet
- Hat finish: Coated
- Rust-resistant coating: Yes
- ABS sensor ring: for trouble-free ABS/TCS operation on ABS/TCS-equipped vehicles
- Condition: New
In the box
One front brake rotor, with bearings included. This listing holds one rotor, and the front axle takes two.
Interchange: 19152696
This part cross-references / interchanges with the following part numbers:
Frequently Asked Questions
Will the Bosch 25010587 fit a 1996-2002 GMC Savana 2500?
Yes, Bosch 25010587 fits the front axle of the 1996-2002 GMC Savana 2500 and the 1996-2002 Chevrolet Express 2500. For any other model, look up your year and engine in the "Vehicles it fits" section.
What is the discard thickness on this Bosch disc rotor?
This front rotor measures 32.6 mm new and reaches its discard thickness at 30.86 mm. The edge code engraved at the factory also carries the discard specification.
Does the Bosch 25010587 rotor come with bearings?
Yes. Bosch 25010587 comes with bearings included, and this listing is one front brake rotor.
Are Bosch QuietCast rotors coated against rust?
Yes. This front rotor has a Geomet disc finish and a coated hat, and its full coating reaches the vanes where applicable to protect against corrosion.
What bolt pattern and diameter does this Bosch QuietCast brake rotor have?
This front rotor is 294.7 mm across, with 6 bolt holes on a 139.7 mm bolt circle and a 65.011 mm center bore.
