RAYBESTOS EHT2283H rear brake pad for the 2017-2026 Tesla 3 and other vehicles presses friction material against the rotor to slow the car. These Raybestos hybrid brake pads combine ceramic and semi-metallic formulations and are made for the rear axle.
- Element3 Hybrid line with EHT Enhanced Hybrid Technology formulations
- Application-specific formulation for quiet operation
- Multi-layer noise-dampening shims for quiet stopping across a wide range of temperatures
- EHT friction blend for pad wear, durability and stopping power during aggressive braking
Quick facts
- Part: RAYBESTOS EHT2283H brake pad
- Also called: disc brake pad set
- Fits: 2017-2026 Tesla 3 and other vehicles
- Position: Rear
- Material: Hybrid friction material
- Condition: New
Squealing, grinding or a longer stopping distance can mean the rear pads are worn, though a seized caliper slide pin or a damaged rotor can be behind them as well, so work out which one it is before buying pads.
Fits
It fits the 2017-2026 Tesla 3 and the 2020-2026 Tesla Y, so it also works as a set of Tesla Y brake pads for the rear axle.
Specifications
Fit and size
- Position: Rear
- Quantity per vehicle: 1 set
- Pad height: 1.950 in (inner and outer)
- Pad width: 5.220 in (inner and outer)
- Pad thickness: 0.585 in (inner and outer)
Build and materials
- Friction material: Hybrid
- Friction attachment: Integrally molded
- Surface: Slotted
- Wear sensor: Mechanical, attached
- Shims and mounting hardware: Included
- Condition: New
- Country of origin: India
In the box
This listing is one rear disc brake pad set with shims, mounting hardware and an attached mechanical wear sensor, and a car needs one set. Brake lubricant is not included.
Interchange / FMSI:
FMSI: D2283-9520
Interchange: 105.22830 · GNAD2283 · CFC2283 · SC2283
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
GNAD2283, CFC2283, SC2283, 105.22830, D2283-9520
Frequently Asked Questions
Do the Raybestos EHT2283H pads fit the 2017-2026 Tesla 3?
Yes, Raybestos EHT2283H rear brake pads fit the 2017-2026 Tesla 3, and the same set fits the 2020-2026 Tesla Y.
Are these Raybestos ceramic brake pads?
No, the friction material is hybrid. Element3 pads combine ceramic and semi-metallic formulations in one pad.
What does EHT mean on Raybestos EHT brake pads?
On the EHT2283H, EHT is Enhanced Hybrid Technology, a blend of friction materials for pad wear, durability and stopping power during aggressive braking.
Do these Raybestos pads come with shims and hardware?
Yes. This rear set includes shims, mounting hardware and an attached mechanical wear sensor. Brake lubricant is not included.
How big are the pads in this rear set?
Each pad measures 0.585 in thick, 5.220 in wide and 1.950 in high, inner and outer alike.
