Front Right CV Axle for 2008-2014 Scion xD - A1 CARDONE 66-5284

$320.99

Vehicles this part fits

    Part number: 66-5284
    UPC: 884548252813
    Condition: New
    Weight: 18.00 LBS
    Item Package Quantity: 1
    $320.99
    Adding to cart… The item has been added

    Have questions?

    CARDONE New CV Axle Assembly P/N:66-5284
    CARDONE New CV Axle Assembly P/N:66-5284
    $320.99
    $320.99

    A1 CARDONE 66-5284 front right CV axle for the 2008-2014 Scion xD carries drive torque from the transaxle to the wheel hub. It is engineered around the ways original axles fail, starting with cracked boots.

    • Neoprene boots with extra bellows where needed to resist bellow stress and cracking, a leading cause of boot failure
    • Shaft verified for straightness, which helps keep vibration down at all speeds
    • New axle retaining nut supplied, since the original nut is likely worn or stripped
    • Boot clamps pneumatically crimped to seal the boot to the housing
    • Grease that withstands high temperature and high torque
    • Splines and threads precision rolled for fit in the hub, transmission and axle nut

    Quick facts

    • Part: A1 CARDONE 66-5284 CV axle
    • Also called: CV axle assembly
    • Fits: 2008-2014 Scion xD
    • Position: Front right
    • Material: Steel shaft, neoprene boots
    • Condition: New

    A torn boot with grease thrown around the chassis, clicking when you turn with the wheel cut, or a thump and vibration under acceleration can mean this CV axle assembly is worn. Those signs can have other causes, so with the engine off and cool, look over the boot for tears and grease before you replace the axle.

    Fits

    It fits the 2008-2014 Scion xD and is built to O.E. form, fit and function. This side takes one; the front left axle is a separate part, ordered separately.

    Specifications

    Fit and size

    • Position: front right
    • Quantity per vehicle: 1 for this side
    • Shaft diameter: 26 mm (1.024 in)
    • Compressed length: 910 mm (35.827 in)
    • Axle nut thread size: M22x1.5
    • Axle nut socket size: 32 mm (1.26 in)
    • Axle nut length: 21.5 mm (0.846 in)
    • Inboard splines: 20
    • Outboard splines: 26

    Build and materials

    • Shaft material: steel
    • Boot material: neoprene, 5 ribs
    • CV joints: included
    • Axle nut: hex, included
    • ABS tone ring: not included
    • Condition: new
    • Country of origin: China

    In the box

    One complete CV axle, one new axle retaining nut and an instruction sheet.

    Installation notes

    • Tighten the axle nut with a torque wrench to the manufacturer's specification; never use an impact wrench.
    • Remove and replace one CV axle at a time.
    • Install new transaxle seals to avoid leaks.
    • Never let the axle hang unsupported, which can separate it and damage the inner joint.

    Interchange: 4341052250

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    4341052250

    Frequently Asked Questions

    Is the A1 CARDONE 66-5284 right for the 2008-2014 Scion xD?

    Yes. A1 CARDONE 66-5284 is the front right CV axle for the 2008-2014 Scion xD. The front left axle is a separate part.

    Do A1 CARDONE axles come with a new axle nut?

    Yes. A1 CARDONE 66-5284 comes with a new hex axle retaining nut (M22x1.5) and an instruction sheet. The ABS tone ring is not included.

    Does this A1 CARDONE CV drive axle have neoprene boots?

    Yes. The boots are neoprene, with extra bellows where needed to resist bellow stress and cracking. The shaft is steel and 26 mm in diameter.

    What are signs this front right CV axle is wearing out?

    Loud clicking or snapping when turning with the wheel cut, a thump and vibration when accelerating, or grease around a torn boot can mean the axle is worn.

    Can I use an impact wrench on the nut of this CV axle?

    No. Use a torque wrench and tighten the nut to the manufacturer's specification. An impact wrench is not appropriate for this nut, and the old transaxle seals should be replaced with new ones.
