CARDONE New 6E-4002 fuel injection throttle body for the 1999-2001 Volkswagen Jetta 4-cylinder 2.0L and other vehicles controls how much air enters the engine. It also takes part in cruise control, traction control and stability control.
- Built and tested as a complete assembly
- Housing, throttle plate, position sensors, throttle actuator motor and return spring made to precise dimensions
- Tested for response time and air flow at multiple points
- Throttle position sensor included
Quick facts
- Part: CARDONE New 6E-4002 fuel injection throttle body
- Fits: 1999-2001 Volkswagen Jetta 4-cylinder 2.0L and other vehicles
- Condition: New
When a throttle body fails, the control module can turn on the check engine light and switch to a fail-safe mode that gradually lowers engine speed to idle. A faulty accelerator pedal sensor, damaged wiring or an intake air leak can be behind those signs too, so find the cause before buying a replacement.
Fits
It also fits the 1999-2001 Volkswagen Golf 4-cylinder 2.0L and the 1998-2001 Volkswagen Beetle 4-cylinder 2.0L. The design matches the O.E. design, and the vehicle needs no modification for installation.
Specifications
Fit and size
- Quantity per vehicle: 1
- Inlet diameter: 65.00 mm (2.559 in)
- Inlet type: Circle
- Bore diameter: 56.00 mm (2.205 in)
- Outlet diameter: 58.00 mm (2.283 in)
- Outlet type: Round
Build and materials
- Condition: New
- Terminal type: Blade
- Throttle position sensor: included
- Electronic components: circuit board
- Country of origin: China
In the box
One throttle body and one instruction sheet. Mounting hardware, a gasket or seal, fuel injectors, an idle air control motor and a throttle body spacer are not included, and the old fasteners may not be reusable. This listing holds one throttle body, and each vehicle takes one.
Installation notes
- A relearn calibration procedure is necessary after installation.
- Where the unit comes without coolant pipes, the instructions cover rerouting the coolant hoses; bypassing the hoses is not recommended.
Interchange: 06A133064H
Frequently Asked Questions
Does CARDONE New 6E-4002 fit the 1998-2001 Volkswagen Beetle 4-cylinder 2.0L?
Yes. CARDONE New 6E-4002 fits the 1998-2001 Volkswagen Beetle 4-cylinder 2.0L, and that vehicle takes one throttle body.
Does this throttle body come with a gasket or mounting bolts?
No. The box holds the throttle body and an instruction sheet. Mounting hardware, a gasket or seal, fuel injectors, an idle air control motor and a spacer are not included.
What bore size does the CARDONE 6E-4002 throttle body have?
The bore is 56.00 mm (2.205 in). The inlet measures 65.00 mm (2.559 in) and the outlet 58.00 mm (2.283 in).
What happens to the engine when a throttle body fails?
The control module can turn on the MIL/SES/CEL light and enter a fail-safe mode that gradually lowers engine speed to idle. Have it checked promptly rather than keep driving.
Does a replacement throttle body need a relearn after installation?
Yes. A relearn calibration procedure is necessary after installing the replacement throttle body, and an instruction sheet comes in the box.
