A1 CARDONE 97-2691 rack and pinion for the 2008-2012 Hyundai Elantra and other vehicles turns steering wheel rotation into the side-to-side motion that steers the wheels. This new rack and pinion assembly is built to perform at OE level or better, and original design weaknesses are identified and improved.
- Built to S.A.E. specifications
- Environmentally friendly coating on the tie rods and lines for a clean appearance and rust prevention
- Performance tested for function and reliable operation
- Computerized spool valve balancing for steering feel
Quick facts
- Part: A1 CARDONE 97-2691 rack and pinion
- Also called: rack and pinion assembly
- Fits: 2008-2012 Hyundai Elantra and other vehicles
- Condition: New
A worn rack and pinion can show up as loose or wandering steering, noise when turning, or a leak around the rack or its boots. Before you replace the rack and pinion, rule out worn tie rod ends, tire wear and alignment, which can cause similar steering symptoms.
Fits
It fits the 2008-2012 Hyundai Elantra, the 2010-2013 Kia Forte and the 2012-2013 Kia Forte5. This listing is one rack and pinion; the 2008-2012 Hyundai Elantra takes one, and so do the Kia models.
Specifications
Fit and size
- Quantity per vehicle: 1
- Mounting holes: 4
- Input shaft type: grooved
- Input shaft splines: 34
- Input shaft diameter: 0.635 in
- Total turns lock to lock: 2.75
Build and materials
- Condition: New
- Coating: environmentally friendly coating on tie rods and lines
- Bellows color: black
- Country of origin: China
In the box
One rack and pinion with its inner tie rods, and an instruction sheet. Outer tie rods, mounting hardware, mounting brackets and a separate seal or gasket are not included, so plan on new mounting bolts, since the old ones may not be reusable.
Interchange: 565002H200 · 565002H300
Frequently Asked Questions
Is this the rack and pinion for a 2011 Hyundai Elantra in the 2008-2012 range?
Yes. The A1 CARDONE 97-2691 fits the 2008-2012 Hyundai Elantra, so a 2011 model is covered.
Does this A1 CARDONE rack and pinion come with outer tie rods?
No. This rack and pinion includes the inner tie rods and an instruction sheet. Outer tie rods, mounting hardware, brackets and a separate seal or gasket are not included.
Does this A1 CARDONE steering rack have a grooved input shaft?
Yes. The input shaft on the A1 CARDONE 97-2691 is grooved, with 34 splines and a 0.635 in diameter, and the rack turns 2.75 times lock to lock.
Could a leak or loose steering mean this rack and pinion is worn?
Possibly. A visible leak or damaged boots with the engine off, or loose steering and noise while driving, can mean wear. A shop can test the steering system to confirm.
Is 565002H200 a number that the A1 CARDONE 97-2691 replaces?
Yes. The A1 CARDONE 97-2691 replaces 565002H200, and 565002H300 is the other number it replaces.
