A1 CARDONE 18-B5537 rear right brake caliper for the 2017-2023 Jeep Compass and other vehicles clamps the brake pad against the rotor to slow the wheel. This remanufactured A1 CARDONE brake caliper, also called a disc brake caliper, comes unloaded, so brake pads are not part of it.
- Steel piston that resists cracking and pitting and handles heavy loads
- New high-temperature EPDM rubber seals in place of the old ones
- 100% pressure-tested after remanufacturing
- Special rust inhibitor treatment applied to the caliper
- New bleeder screw, plus new stainless steel hardware clips and mounting pins where applicable
Quick facts
- Part: A1 CARDONE 18-B5537 brake caliper
- Also called: disc brake caliper
- Fits: 2017-2023 Jeep Compass and other vehicles
- Position: Rear right
- Material: Cast iron
- Condition: Remanufactured
A rear right caliper that is worn or failing can show up as a pull to one side under braking, uneven pad wear or brake fluid around the caliper. Those signs can also come from a collapsed brake hose or binding slide pins, so find the cause before you replace the caliper.
Fits
This brake caliper fits the 2017-2023 Jeep Compass, the 2023-2024 Dodge Hornet and the 2015-2023 Jeep Renegade, among other vehicles. If your vehicle is not named here, look up your year, make and model in the "Vehicles it fits" section.
Specifications
Fit and size
- Position: Rear right
- Quantity per vehicle: 1
- Piston diameter: 38.17 mm (1.503 in)
- Mounting hole diameter: 11.98 mm (0.472 in)
- Mounting hole thread: M12x1.25
- Inlet port size: 10.00 mm (0.394 in)
- Inlet fitting: banjo, thread M10x1.0
- Bleeder thread: M10x1.0
Build and materials
- Condition: Remanufactured
- Caliper type: Floating, 1 piston
- Piston material: Steel
- Casting material: Cast iron
- Finish: Oil emulsion
- Rust-resistant coating: Yes
- Country of origin: Mexico
In the box
One rear right caliper with its bracket, a hardware kit and an instruction sheet. The rear right side takes one caliper; the rear left is a separate part ordered on its own, and the two sides are normally replaced together. Brake pads and mounting bolts are not included, so plan on new mounting bolts.
Installation notes
- A plastic cap plug protects each brake port thread until installation.
- Silicone grease is used on floating caliper mounting pins.
- Use the brake fluid type stamped on the master cylinder reservoir lid, from a sealed container of new fluid.
Interchange: 68263295AA · 68338708AA
Frequently Asked Questions
Is this the right Hornet brake caliper for the 2023-2024 Dodge Hornet?
Yes. A1 CARDONE 18-B5537 is the rear right caliper for the 2023-2024 Dodge Hornet. The rear left side is a separate part.
Does this A1 CARDONE caliper come with a bracket and hardware?
Yes. A1 CARDONE 18-B5537 comes with the caliper, mounting bracket, hardware kit and instruction sheet. Brake pads and mounting bolts are not included.
How big is the piston on this rear right caliper, and what is it made of?
The piston is steel and 38.17 mm (1.503 in) across. The caliper is a floating design with a single piston.
Brakes squeal after fitting a new caliper: what should I check?
Squeal can come from brake pads that were installed improperly, brake hardware that was installed improperly, or an improper rotor finish. Make sure the hardware in the box is fitted correctly.
Does 18-B5537 replace part number 68263295AA?
Yes. 68263295AA is listed as an interchange number for A1 CARDONE 18-B5537, along with 68338708AA.
