Champion 9034 spark plug for the 1997-2002 Jeep Wrangler 4-cylinder 2.5L, the 1997-2006 Wrangler 6-cylinder 4.0L and other vehicles fires the spark that lights the air-fuel mixture in the cylinder.
- Champion Iridium series spark plug with a resistor
- Iridium center electrode for long-term reliability and consistent performance
- Fine-wire center electrode for faster, more efficient ignition
- Platinum-enhanced ground electrode to target the spark for combustion
- Pre-gapped design simplifies installation; the gap is 0.045 in (1.15 mm)
- Coated shell resists corrosion in harsh environments
Quick facts
- Part: Champion 9034 spark plug
- Fits: the 1997-2002 Jeep Wrangler 4-cylinder 2.5L, the 1997-2006 Wrangler 6-cylinder 4.0L and other vehicles
- Material: Iridium center electrode with platinum ground electrodes
- Condition: New
Hard starting, a rough idle or a misfire can mean the plugs are worn. Coils and injectors can show up the same way, so with the engine off and cool, look at a removed plug's electrode, insulator and gap before settling on the plug.
Fits
It is listed for a wide range of Dodge, Chrysler and Jeep models, with the 2006-2010 Dodge Charger V6 3.5L among them, and these plugs also go in the 2004-2006 Dodge Ram 1500 V10 8.3L. Built to meet OE fit, form and function. One plug goes in each cylinder, so the number you need follows the engine's cylinder count. If your car is not named here, open the "Vehicles it fits" section and check your exact model and engine.
Specifications
Fit and size
- Thread diameter: 14 mm (0.551 in)
- Pre-gap: 0.045 in (1.15 mm)
- Seat type: Flat
- Quantity: one per cylinder
Build and materials
- Series: Champion Iridium, performance grade
- Center electrode: iridium
- Ground electrode: platinum, J gap
- Resistor type: Yes
- Washer: crush, included
- Condition: New
- Country of origin: China
In the box
One spark plug with a crush washer.
Interchange: XP5405 · RC12WEPB5 · SZFR5000AA · SP000ZFR5N · 5899 · 7B0905600
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
XP5405, RC12WEPB5, SZFR5000AA, SP000ZFR5N, 5899, 7B0905600
Frequently Asked Questions
Is this the right Charger plug for a 2006-2010 Dodge Charger V6 3.5L?
Yes. Champion 9034 is listed for the 2006-2010 Dodge Charger V6 3.5L, which takes six plugs, one in each cylinder.
Does this Jeep Wrangler plug fit the 1997-2002 4-cylinder 2.5L and the 1997-2006 6-cylinder 4.0L?
Yes, Champion 9034 is listed for the 1997-2002 Jeep Wrangler 4-cylinder 2.5L and the 1997-2006 Wrangler 6-cylinder 4.0L; use the "Vehicles it fits" section to check other models and engines.
Does this iridium spark plug come with a washer and a preset gap?
Yes. It includes a crush washer and is pre-gapped at 0.045 in (1.15 mm).
Is this Champion Iridium plug a resistor type, and what are its electrodes made of?
Yes, it is a resistor type. The center electrode is iridium and the ground electrodes are platinum.
Does Champion 9034 cross-reference to plug code RC12WEPB5?
Yes. RC12WEPB5 is listed as an interchange number for Champion 9034, so you can match it against that code.
