MOOG RK622215 front right lower control arm with ball joint for the 2011-2019 Ford Explorer and other vehicles holds the right front wheel in position as the suspension moves. This MOOG lower control arm, also called a control arm and ball joint assembly, arrives with the ball joint and bushings pre-installed.
- Induction-hardened studs resist breakage and improve fatigue life
- Patent-pending carbon fiber-reinforced bearing reduces socket friction for longer socket life
- Greaseable socket lets new lubricant flush out contaminants
- Pre-installed dust boot seal keeps dirt and water out
- Specially engineered coatings on the metal surfaces inhibit premature deterioration from rain, snow, salt and road grime
- Pre-installed bushings with optimized stiffness inhibit noise
Quick facts
- Part: MOOG RK622215 control arm with ball joint
- Also called: control arm and ball joint assembly
- Fits: 2011-2019 Ford Explorer and other vehicles
- Position: Front right lower
- Material: Rubber (bushings)
- Condition: New
A clunk over bumps, uneven tire wear or a loose steering feel can come from a worn arm, bushing or ball joint, and from other suspension parts too. With the engine off, look for a torn dust boot, split rubber or leaking grease, and have a shop check for play before you replace anything.
Fits
It fits the 2011-2019 Ford Explorer and the 2013-2019 Ford Police Interceptor Utility.
Specifications
Fit and size
- Position: Front right lower
- Quantity for this side: 1
- Ball joint mounting type: Press in
- Ball joint stud type: Threaded
- Adjustable: No
Build and materials
- Bushing material: Rubber
- Greaseable socket with grease fitting
- Laser-etched MOOG ID
- Condition: New
- Country of origin: Taiwan
In the box
One front right lower control arm with the ball joint, bushings and grease fitting, plus the hardware needed for installation. This listing is one arm for the front right, which takes one; the front left is a separate part ordered on its own, and both sides are normally replaced together.
Installation notes
- Precision tolerances are made for easy installation and steering alignment.
Interchange: 520-786
GB5Z3078C · GB5Z3078D · GB5Z3078E · GB5Z3078H · GB5Z3078J · 6CB40487 · MCF2389 · MCF2392
This part cross-references / interchanges with the following part numbers:
520-786, GB5Z3078C, GB5Z3078D, GB5Z3078E, GB5Z3078H, GB5Z3078J, 6CB40487, MCF2389, MCF2392
