Delphi Fuel Injection Idle Air Control Valve CV10160

Delphi Fuel Injection Idle Air Control Valve CV10160 - view 2

Delphi Fuel Injection Idle Air Control Valve CV10160 - view 3

Delphi Fuel Injection Idle Air Control Valve CV10160 - view 4

Delphi Fuel Injection Idle Air Control Valve P/N:CV10160

Be the first to review this product

$50.99

MPN: CV10160

UPC: 689604162705

Item Package Quantity: 1

Current Stock:

Quantity:

Adding to cart… The item has been added

Have questions?

Ask an Expert

Delphi Fuel Injection Idle Air Control Valve P/N:CV10160

$50.99

Description

Hold a steady, controlled idle with the Delphi Idle Air Control Valve CV10160. This electronically controlled valve regulates the air that bypasses the closed throttle plate, letting the engine control module set idle speed. It installs as a direct-fit replacement for the 1998-2003 Chevrolet S10, 1998-2003 GMC Sonoma, and 1998-2000 Isuzu Hombre.

Idle air metering: Opens and closes an air-bypass passage around the throttle plate so the control module can hold a stable idle across operating conditions.
Cold-start and load response: Adjusts bypass airflow during warm-up and when accessory loads change, helping keep idle from sagging.
Signs it may need replacing: Rough or surging idle, unexpected stalling, or hard starting can indicate a worn idle air control valve — diagnose the cause first, since these symptoms have other sources.

The valve handles metered intake air at the throttle body, not an air-fuel mixture. If a failed idle air control valve is the cause of your idle problem, this Delphi unit replaces it. Because idle faults can also come from vacuum leaks, throttle deposits, or sensor issues, confirm the diagnosis before replacing.

Interchange: 12482707 · 2H1048 · 28975 · 218795 · 17076174 · 17076302 · 17113297 · 8-12482-707-0 · 8124827070 · 8-19418-036-0 · 8194180360 · 150-140 · 150140 · SE96059 · AC160 · 215-1034 · 2151034 · AC138
Manufacturer part number CV10160.

Manufacturer's Description

Product Specs

Buyer's Guide

Interchange Part Numbers

This part cross-references / interchanges with the following part numbers:

12482707, 2H1048, 28975, 218795, 17076174, 17076302, 17113297, 8-12482-707-0, 8-19418-036-0, 150-140, SE96059, AC160, 215-1034, AC138

Frequently Asked Questions

What does the Delphi CV10160 do?

It's an idle air control valve that regulates the air bypassing the closed throttle plate, letting the engine control module maintain a stable idle speed across operating conditions.

Which vehicles does this fit?

It's a direct-fit replacement for the 1998-2003 Chevrolet S10, 1998-2003 GMC Sonoma, and 1998-2000 Isuzu Hombre. See the Buyer's Guide tab to confirm your vehicle.

What are signs my idle air control valve may be failing?

Rough or surging idle, unexpected stalling, and hard starting can point to a worn IAC valve, but confirm the cause since vacuum leaks or throttle deposits can produce the same symptoms.

What part numbers does this replace?

It interchanges with 12482707, 2H1048, 28975, 218795, 17076174, 17076302, 17113297, 8-12482-707-0, 8-19418-036-0, 150-140, SE96059, AC160, 215-1034 and AC138.

Will replacing this valve fix a rough idle?

If a failed idle air control valve is the cause, this replaces it. Rough idle can also stem from vacuum leaks, throttle-body deposits, or sensor faults, so diagnose before installing.
