Fuel Pump Module for 2004-2008 Suzuki Forenza & More - Delphi FG1181

$316.99
WARNING:California Proposition 65▾
Delphi Fuel Pump Module Assembly FG1181
Delphi Fuel Pump Module Assembly FG1181 - view 2
Delphi Fuel Pump Module Assembly FG1181 - view 3
Delphi Fuel Pump Module Assembly FG1181 - view 4
Delphi Fuel Pump Module Assembly FG1181 - view 5
Delphi Fuel Pump Module Assembly FG1181 - view 6
Delphi Fuel Pump Module Assembly FG1181 - view 7
Delphi Fuel Pump Module Assembly FG1181 - view 8
Delphi Fuel Pump Module Assembly FG1181 - view 9
Delphi Fuel Pump Module Assembly FG1181
Delphi Fuel Pump Module Assembly FG1181 - view 2
Delphi Fuel Pump Module Assembly FG1181 - view 3
Delphi Fuel Pump Module Assembly FG1181 - view 4
Delphi Fuel Pump Module Assembly FG1181 - view 5
Delphi Fuel Pump Module Assembly FG1181 - view 6
Delphi Fuel Pump Module Assembly FG1181 - view 7
Delphi Fuel Pump Module Assembly FG1181 - view 8
Delphi Fuel Pump Module Assembly FG1181 - view 9

Vehicles this part fits
    Part number: FG1181
    UPC: 689604231555
    Condition: New
    Weight: 6.32 LBS
    Item Package Quantity: 1
    $316.99
    Adding to cart… The item has been added

    Have questions?

    Ask an Expert
    Delphi Fuel Pump Module Assembly P/N:FG1181
    Delphi Fuel Pump Module Assembly P/N:FG1181
    $316.99
    $316.99

    Delphi FG1181 fuel pump module for the 2004-2008 Suzuki Forenza 4-cylinder 2.0L and other vehicles sends fuel from the tank to the engine. Also called a fuel pump assembly, it is built to Delphi's OE standards.

    • Empty float height and float retention set for a correct gas gauge reading
    • Low amperage draw keeps the load on the vehicle's electrical system down
    • Delphi fuel pump module validated, tested and matched to the right vehicle application
    • Design and durability reduce the failure rate

    Quick facts

    • Part: Delphi FG1181 fuel pump module
    • Also called: fuel pump assembly
    • Fits: 2004-2008 Suzuki Forenza 4-cylinder 2.0L and other vehicles
    • Condition: New

    Hard starting, stalling or an erratic fuel gauge can mean the module is wearing out. These signs alone do not prove the module is the problem, since a fuel pump relay fault can produce some of them too.

    Fits

    It fits the 2004-2008 Suzuki Forenza 4-cylinder 2.0L and the 2005-2008 Suzuki Reno 4-cylinder 2.0L, and both cars take a single module.

    Specifications

    • Quantity per vehicle: 1
    • Condition: New

    In the box

    One fuel pump module, supplied without a float arm, seal or instruction sheet.

    Installation notes

    • Check the fuel tank and clean it before installing the module.

    Interchange: 15100-85Z00 · 15100-85Z01 · 15100-85Z02
    4010481 · E8703M · CFG1181 · 69926 · P77221M · A25513 · SP4071M · USEP8703M

    This part cross-references / interchanges with the following part numbers:

    4010481, E8703M, CFG1181, 69926, P77221M, A25513, SP4071M, 15100-85Z00, 15100-85Z01, 15100-85Z02, USEP8703M

    Frequently Asked Questions

    Will the Delphi FG1181 fit a 2005-2008 Suzuki Reno 4-cylinder 2.0L?

    Yes. Delphi FG1181 fits the 2005-2008 Suzuki Reno 4-cylinder 2.0L, and that car takes one module.

    Does the Delphi fuel pump module assembly come with a float arm?

    No. This Delphi FG1181 listing is the fuel pump module supplied without a float arm, seal or instruction sheet.

    Is the float on this Delphi fuel module set to OE specifications?

    Yes. The empty float height and float retention match OE specifications, which gives a correct gas gauge reading.

    Does this Delphi module draw less current from the electrical system?

    Yes. This fuel pump module's lower amperage draw puts less load on the vehicle's electrical system.

    Does Delphi FG1181 replace the 15100-85Z00 fuel pump module?

    Yes. 15100-85Z00 is on the interchange list for Delphi FG1181.
