Rear Brake Rotor for 1999-2004 Chevrolet Silverado 2500 & More - Bosch 25010543

Be the first to review this product
$88.99
MPN: 25010543
Item Package Quantity: 1
Adding to cart… The item has been added

Have questions?

Bosch Disc Brake Rotor P/N:25010543
Bosch Disc Brake Rotor P/N:25010543
$88.99

Bosch 25010543 rear brake rotor for the 1999-2004 Chevrolet Silverado 2500 and other vehicles is the disc the pads squeeze to slow the wheel. This Bosch brake rotor, also called a disc brake rotor, comes without a hub assembly.

  • 100% precision balanced to minimize vibration and keep operation smooth
  • Low run-out and DTV specifications for a smooth pedal feel with no pulsation
  • Heat flowed castings for consistent wear, quiet operation and long life
  • Vented design with vanes for heat dissipation from the braking system
  • Full coating, including the vanes where applicable, protects against corrosion
  • Factory-engraved edge code for identification and the discard specification

Quick facts

  • Part: Bosch 25010543 brake rotor
  • Also called: disc brake rotor
  • Fits: the 1999-2004 Chevrolet Silverado 2500 and other vehicles
  • Position: Rear
  • Condition: New

Pedal pulsation, a grinding or squealing noise, or visible grooves and rust on the disc can mean a rotor is worn. Before you replace the rotor, rule out a sticking caliper or worn pads, since they can show up with similar signs.

Fits

The vehicles it fits include the 1999-2004 Chevrolet Silverado 2500, the 2011-2016 Chevrolet Express 3500 V8-6.6L and the 2010-2016 GMC Savana 3500 V8-6.6L, and each takes two. This listing is one rear rotor, and the other rear side is normally replaced at the same time. If your truck or van is not named here, look it up on the Buyer's Guide tab.

Specifications

Fit and size

  • Position: rear
  • Quantity per vehicle: 2
  • Center bore diameter: 123 mm
  • Thickness: 29 mm (nominal)

Build and materials

  • Construction: vented, without hub assembly
  • Coating: Geomet
  • Balancing: 100% precision balanced
  • ABS sensor ring: for trouble-free ABS and traction control operation on equipped vehicles
  • Condition: new

Interchange: 15712803

This part cross-references / interchanges with the following part numbers:

15712803

Frequently Asked Questions

Will the Bosch 25010543 rear rotor fit the 2011-2016 Chevrolet Express 3500 V8-6.6L?

Yes. Bosch 25010543 is listed for the 2011-2016 Chevrolet Express 3500 V8-6.6L, and each one takes two. Other trucks and vans are on the Buyer's Guide tab.

Does this Bosch disc rotor come with the hub?

No. Bosch 25010543 is a vented rear rotor sold without a hub assembly. Its center bore diameter is 123 mm.

Do these Bosch QuietCast rotors have ABS sensor rings?

Yes. The rotor has ABS sensor rings for trouble-free ABS and traction control operation on vehicles equipped with them.

Where do I find the discard thickness on this Bosch QuietCast brake rotor?

Look at the factory-engraved edge code on the rotor, which includes the discard specification. Nominal thickness is 29 mm.

Is 15712803 an interchange number for the Bosch QuietCast Premium disc brake rotor?

Yes. 15712803 is listed as an interchange number for the Bosch 25010543 rear brake rotor.
