Dorman 090-006 oil drain plug for the 1949-1955 Cadillac Commercial Chassis V8 5.4L, the 1956-1958 Commercial Chassis V8 6.0L, the 1959-1963 Commercial Chassis V8 6.4L, the 1964-1965 Commercial Chassis V8 7.0L and other vehicles closes the oil drain opening and lets the oil out when it is removed. It is intended to replace a missing or damaged plug and help keep a secure seal.
- Dorman Autograde product line
- Replaces a missing or damaged plug to help ensure a secure seal
- Steel construction made to strict specifications
- Fine SAE thread, 5/8-18
- Hex head, 7/8 in head size
- Gasket or seal included with the plugs
Quick facts
- Part: Dorman 090-006 oil drain plug
- Also called: engine oil drain plug
- Fits: 1949-1955 Cadillac Commercial Chassis V8 5.4L, the 1956-1958 Commercial Chassis V8 6.0L, the 1959-1963 Commercial Chassis V8 6.4L, the 1964-1965 Commercial Chassis V8 7.0L and other vehicles
- Material: Steel
- Condition: New
Oil spots where the car is parked, or a rounded hex head or stripped threads found at an oil change, can mean the plug needs replacing. These signs alone do not prove the plug is at fault, since a leaking oil filter or pan gasket can leave a similar spot.
Fits
It is a direct-fit replacement for the Commercial Chassis runs above. Fitment also covers the 1953-1955 Cadillac DeVille V8 5.4L, the 1956-1958 DeVille V8 6.0L, the 1959-1963 DeVille V8 6.4L, the 1964-1965 DeVille V8 7.0L and the 1953-1955 Cadillac Eldorado V8 5.4L, the 1956-1958 Eldorado V8 6.0L, the 1959-1963 Eldorado V8 6.4L and the 1964-1965 Eldorado V8 7.0L. The 1949-1955 Commercial Chassis V8 5.4L takes one plug, and this listing holds five.
Specifications
Fit and size
- Thread size: 5/8-18 (5/8 in diameter, 18 threads per inch)
- Thread type: fine, SAE
- Head size: 7/8 in
- Length: 0.5 in
- Quantity per vehicle: 1
- Plugs per listing: 5
Build and materials
- Material: steel
- Head drive: hex
- Bolt grade: 3
- Gasket or seal: included
- Magnetic: no
- Condition: new
- Country of origin: China
In the box
Five oil drain plugs, with a gasket or seal included.
Interchange: DN090-006 · K 01565 · 263-720
1307238 · 01565 · KT11759
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
DN090-006, 1307238, 01565, K 01565, KT11759, 263-720
Frequently Asked Questions
Is the Dorman oil plug 090-006 right for the 1949-1955 Cadillac Commercial Chassis V8 5.4L?
Yes. Dorman 090-006 fits the 1949-1955 Cadillac Commercial Chassis V8 5.4L. If your car is another model, look it up in the "Vehicles it fits" section on this page.
Does the Dorman engine oil drain plug come with a gasket?
Yes. Dorman 090-006 comes as five oil drain plugs with a gasket or seal included.
What thread does the Dorman Autograde oil drain plug use?
This plug has a fine SAE thread, 5/8-18 (18 threads per inch), and a hex head with a 7/8 in head size.
Does the Dorman drain plug 090-006 replace part number 263-720?
Yes. 263-720 is one of the interchange numbers listed for Dorman 090-006, along with DN090-006 and K 01565.
Is this Dorman oil drain plug magnetic?
No. This steel plug is listed as non-magnetic.
