Turn pedal effort into hydraulic braking pressure with the Dorman First Stop Brake Master Cylinder M630671, a new Honda Fit master cylinder that is a direct-fit replacement for the 2009-2014 Honda Fit and 2010-2014 Honda Insight (all engines). Dorman engineered it to match the original master cylinder's design, function and performance on the listed applications. It is built from new, high-quality materials.
A brake master cylinder converts the force at the brake pedal into hydraulic pressure. It sends that pressure through its two outlets and the brake lines to the wheels. If a worn or leaking master cylinder is the cause of a soft or sinking pedal, this unit replaces it.
Specifications: 1.063-inch bore diameter, two outlets, M12 x 1.0 rearward and secondary outlet threads, and a 1 mm primary outlet thread pitch. The package contains one master cylinder. The reservoir, sensor and mounting hardware are not included. Transfer or replace the reservoir and sensor as directed by the service procedure. Consult the vehicle service information for the correct fasteners and whether they may be reused. Country of origin: Taiwan.
Interchange: 100-2861 · 13-4331 · 11-4331 · 130.40077 · 355-59054
1002861 · 134331 · 114331 · 13040077 · 35559054 · 46101TK6306 · NM55431 · MC391363 · F143697 · MC143697
This part cross-references / interchanges with the following part numbers:
Which vehicles does this brake master cylinder fit?
It is a direct-fit replacement for the 2009-2014 Honda Fit and the 2010-2014 Honda Insight, all engines. Check the Buyer's Guide tab to confirm your vehicle.
Does it come with a reservoir or sensor?
No. The reservoir, sensor and mounting hardware are not included. Transfer or replace the reservoir and sensor as the service procedure directs, and check the service information for the correct fasteners.
What are the key specifications of M630671?
It has an aluminum housing, a 1.063-inch bore and two outlets. The rearward and secondary outlets use M12 x 1.0 threads, and the primary outlet has a 1 mm thread pitch.
What are the rubber components made of?
All rubber components are made of a high-quality EPDM compound for resistance to glycol-based brake fluid.
What are signs a master cylinder may need replacing?
A soft or sinking brake pedal, fluid leaking at the master cylinder, or a brake warning light can be signs. Other brake parts can cause these symptoms too, so diagnose the system first.
