Dorman 1590361 left headlight assembly for the 2010-2013 Ford Transit Connect houses the bulbs and lens that light the road ahead. This Dorman headlight assembly is reverse-engineered to match the stock headlight's dimensions and look.
- Rigid plastic housing with a clear polycarbonate lens
- Two halogen bulbs included for high beam and low beam
- Reflector light projection design
- Street-legal headlight assembly
Quick facts
- Part: Dorman 1590361 headlight assembly
- Fits: 2010-2013 Ford Transit Connect
- Position: Left
- Material: Plastic housing, polycarbonate lens
- Condition: New
A cracked lens, moisture inside the housing or a beam that has gone dim or dark can mean the assembly is damaged. With the engine off, look over the lens and housing, then inspect the bulb and its connector, because a weak bulb or a loose connector can also dim a beam.
Fits
This left headlight assembly is a direct-fit replacement for the 2010-2013 Ford Transit Connect, which takes one on the left side. The listing is a single piece, the right side is ordered separately, and the two are normally replaced together.
Specifications
Fit and size
- Position: Left
- Quantity per vehicle: 1
- Beam type: High beam and low beam
- Voltage: 12 V DC
- High beam wattage: 55 W
Build and materials
- Type: Assembly with reflector light projection
- Housing material: Plastic
- Lens material: Polycarbonate, clear
- Bulbs: 2 halogen bulbs included
- Street legal: Yes
- Condition: New
- Country of origin: Taiwan
In the box
One left headlight assembly with its bulbs. Mounting hardware and the adjusting screw are not included, and the old hardware may not be reusable, so plan on new pieces.
Interchange: 7L1Z13008DB · 9T1Z13008A · 9T1Z13008C
This part cross-references / interchanges with the following part numbers:
7L1Z13008DB, 9T1Z13008A, 9T1Z13008C
Frequently Asked Questions
Does Dorman 1590361 work as one of the 2012 Ford Transit Connect headlights?
Yes. Dorman 1590361 is the left headlight assembly for the 2010-2013 Ford Transit Connect, so it covers the 2012 model year. The right side is a separate part.
Does this left headlight assembly come with bulbs?
Yes. It includes two halogen bulbs. Mounting hardware and the adjusting screw are not included.
Is the lens on Dorman 1590361 glass or plastic?
Dorman 1590361 has a clear polycarbonate lens in a plastic housing. The light projection design is a reflector.
My headlight lens looks foggy inside. Does the assembly need replacing?
Moisture or fogging inside the lens, or a crack in the lens or housing, can mean the assembly is damaged. A shop can confirm it.
Is this headlight assembly high beam, low beam or both?
It covers both. The beam type is high beam and low beam, and the high beam wattage is 55 W on a 12-volt DC system.
