Dorman 620-938 A/C condenser fan for the 2015-2016 Honda CR-V spins air across the condenser to help the A/C system shed heat. This AC condenser fan assembly comes with the shroud, blade and motor pre-assembled.
- Plug-and-play electrical connector, no splicing needed
- Seven plastic blades with a forward align fin design
- Brushed electric motor that runs on 12 V DC
- Components are tested in laboratory settings
Quick facts
- Part: Dorman 620-938 A/C condenser fan
- Also called: AC condenser fan assembly
- Fits: 2015-2016 Honda CR-V
- Material: Plastic
- Condition: New
Warm air from the vents at idle or in traffic, a noisy fan, or a fan that does not spin can mean the condenser fan has failed. Before you replace it, rule out a blown fuse, a bad relay or a damaged connector, since any of them can also leave a fan idle. The 2015-2016 Honda CR-V takes a single fan, one for the condenser.
Fits
This condenser fan fits the 2015-2016 Honda CR-V, and the listing is one fan.
Specifications
Fit and size
- Quantity per vehicle: 1
- Fan diameter: 350 mm
- Shaft diameter: 5 mm
- Shaft length: 20 mm
- Hub bolt hole diameter: 110 mm, 3 holes
- Mount type: bracket
- Connector: male, 2 terminals
Build and materials
- Material: plastic
- Shroud: included, plastic
- Blade type: forward align fin, clockwise rotation
- Grade: standard replacement
- Condition: New
- Country of origin: Taiwan
In the box
One A/C condenser fan with its shroud.
Interchange: 2812073 · 2812248 · 38611RMXA51 · 386155LAA01 · 386165LAA01 · 611520
This part cross-references / interchanges with the following part numbers:
2812073, 2812248, 38611RMXA51, 386155LAA01, 386165LAA01, 611520
Frequently Asked Questions
Is the Dorman 620-938 condenser fan right for the 2015-2016 Honda CR-V?
Yes. Dorman 620-938 fits the 2015-2016 Honda CR-V, and the car takes one fan. This listing is a single fan.
Does the Dorman 620-938 fan come with the shroud and motor?
Yes. The shroud, blade and motor come pre-assembled as one condenser fan, so you get the shroud with the motor already attached.
How wide is this condenser fan?
The fan is 350 mm across with seven plastic blades. Its brushed electric motor runs on 12 V DC and mounts on a bracket.
Could a weak A/C at idle come from a bad condenser fan?
It can. Warm air at idle or in traffic, a noisy fan or a fan that does not spin can mean the fan has failed. A shop can test it with the engine running.
Does the 620-938 condenser fan need wiring splices?
No. Dorman 620-938 has a plug-and-play male connector with 2 terminals, so no splicing is needed.
