Dorman 624-576 transmission oil cooler hose for the 2005-2006 Ford F-150 V8 4.6L or 5.4L and other vehicles carries transmission fluid between the auxiliary cooler and the radiator. Also called an automatic transmission oil cooler hose assembly, it replaces a line that leaks or has failed from corrosion, collision, vibration or fitting damage.
- Part of the Dorman OE Solutions line
- Rubber and metal hose material in a flexible molded assembly
- Quick-disconnect fitting on one end and male threads on the other
- Maximum working pressure of 100 psi, operating range of -40°F to 329°F
Quick facts
- Part: Dorman 624-576 transmission oil cooler hose
- Also called: automatic transmission oil cooler hose assembly
- Fits: 2005-2006 Ford F-150 V8 4.6L or 5.4L and other vehicles
- Position: auxiliary cooler to radiator
- Material: rubber and metal
- Condition: New
Transmission fluid leaking at a line or fitting, or a corroded or crushed line, can mean the hose needs replacing. A leaking auxiliary cooler, a worn O-ring or a loose radiator fitting can be behind a fluid leak too, so find the source before you buy a new hose. Each truck needs just one, running from the auxiliary cooler to the radiator.
Fits
It is a direct replacement for the 2005-2006 Ford F-150 V8 4.6L or 5.4L and the 2006 Lincoln Mark LT V8 5.4L.
Specifications
Fit and size
- Position: auxiliary cooler to radiator
- Quantity per vehicle: 1
- Length: 76.5 in
- End 1 inside diameter: 0.227 in
- End 1 type: quick disconnect
- End 2 type: male threads
Build and materials
- Hose material: rubber and metal
- Hose shape: molded assembly
- Flexible: yes
- Maximum working pressure: 100 psi
- Operating temperature: -40°F to 329°F
- Condition: New
- Country of origin: China
In the box
Four transmission lines, six threaded end connectors, four O-rings and two retaining clips.
Interchange: 5L3Z7R081CB
Frequently Asked Questions
Does the Dorman 624-576 fit the 2005-2006 Ford F-150 with the 5.4L V8?
Yes. Dorman 624-576 fits the 2005-2006 Ford F-150 V8 4.6L or 5.4L, and the 2006 Lincoln Mark LT V8 5.4L.
Do the 624-576 transmission oil cooler lines come with O-rings and clips?
Yes. The box holds four transmission lines, six threaded end connectors, four O-rings and two retaining clips.
What fittings are on the ends of this transmission oil cooler hose?
One end is a quick disconnect and the other has male threads. The hose is 76.5 inches long, with a 0.227 inch inside diameter at the quick-disconnect end.
How can I tell if a transmission oil cooler line has failed?
Look for transmission fluid leaking at a line or fitting, or a line that is corroded or damaged. Check only with the engine off and cool; a shop can pinpoint the source.
What pressure and temperature can Dorman 624-576 handle?
Dorman 624-576 has a maximum working pressure of 100 psi and an operating temperature range of -40°F to 329°F.
