Keep automatic transmission fluid moving cleanly between the transmission and the oil cooler with the Dorman - OE Solutions Automatic Transmission Oil Cooler Line Connector 800-714. This metal fitting ties into the transmission cooler line, and it installs as a direct-fit replacement for the 1987-2000 Jeep Cherokee (L4-2.5L), 1987-2001 Jeep Cherokee (L6-4.0L), 1987-1992 Jeep Comanche (L4-2.5L and L6-4.0L), 1993 Jeep Grand Cherokee (L6-4.0L and V8-5.2L), 1987 Jeep Wagoneer (L4-2.5L), and 1987-1990 Jeep Wagoneer (L6-4.0L). If a cracked or leaking original connector is the source of a cooler-line leak, this replaces it.
Fitting specification: 3/8 in. OD tube by 14 mm-1.5, with a male-thread end and a straight fitting angle.
Quick-disconnect end: the opposite end (End 2) is a quick-disconnect connection.
Durable metal build: made of quality materials for a precise fit.
Pressure tested: rigorously pressure tested to help support reliable, leak-free performance.
In the box: one transmission line connector; no thread sealer is applied.
A handy supply to keep on hand any time the transmission oil cooler line is being serviced. Country of origin: China. Manufacturer part number 800-714 (also 800714).
This part cross-references / interchanges with the following part numbers:
83503728
Frequently Asked Questions
What does the Dorman 800-714 connector do?
It joins the automatic transmission oil cooler line between the transmission and the oil cooler, providing a connection point in the fluid path with a threaded end and a quick-disconnect end.
Which vehicles does this connector fit?
It's a direct-fit replacement for the 1987-2000 Jeep Cherokee (L4-2.5L), 1987-2001 Cherokee (L6-4.0L), 1987-1992 Comanche, 1993 Grand Cherokee (L6-4.0L, V8-5.2L), and 1987-1990 Wagoneer. See the Buyer's Guide tab for the full list.
What are the fitting specifications?
One end is a 14 mm-1.5 male thread for a 3/8 in. OD tube with a straight fitting angle; the other end (End 2) is a quick-disconnect connection.
Does it come with thread sealer?
No. The Thread Sealer Present attribute is listed as No, so no sealer is applied. Consult the vehicle service information for the correct sealing and torque procedure.
How many are included and where is it made?
The package contains one transmission line connector, and its country of origin is China.
