Dorman 620-662 radiator fan for the 2017-2019 GMC Acadia V6 3.6L and other vehicles pulls air through the radiator to cool the engine. The assembly is designed with the same materials and components as the original part and is tested to cool as effectively.
- Brushless electric motor rated 12 V DC at 39.9 A
- 11 forward-align fin blades on a 580 mm fan, rated at 2201.63 CFM
- Motor, plastic shroud, blades, wiring harness and control module come as one assembly
- Oval plug-in connector with two male blade terminals
- Motors are tested in laboratory settings for performance
Quick facts
- Part: Dorman 620-662 radiator fan
- Also called: cooling fan assembly
- Fits: 2017-2019 GMC Acadia V6 3.6L and other vehicles
- Material: Plastic
- Condition: New
A fan that stays still when the engine is hot, cracked blades or a damaged shroud can mean the assembly is worn out. Before you replace it, rule out a blown fuse, a faulty relay and a coolant problem, because those can leave a good fan idle or let the engine run hot. This listing is one fan assembly, and a single fan per vehicle is all these engines need.
Fits
It fits the 2017-2019 GMC Acadia V6 3.6L, the 2019 Chevrolet Blazer V6 3.6L and the 2017-2019 Cadillac XT5 V6 3.6L. It is designed to match the fit and performance of the stock radiator fan on them.
Specifications
Fit and size
- Quantity per vehicle: 1
- Fan diameter: 580 mm
- Blade count: 11
- Shaft diameter: 5 mm
- Shaft length: 5 mm
- Hub bolt hole diameter: 10 mm, 4 hub bolt holes
- Terminals: 2
Build and materials
- Type: electric, brushless motor, no fan clutch
- Material: Plastic (blades, housing and shroud)
- Voltage: 12 V DC
- Rotation: clockwise (right)
- Connector: oval, plug-in
- Condition: New
- Country of origin: China
In the box
One radiator fan assembly.
Interchange: 75192 · 23412300 · 23419653
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
75192, 23412300, 23419653
Frequently Asked Questions
Does the Dorman 620-662 radiator fan fit the 2019 Chevrolet Blazer V6 3.6L?
Yes. Dorman 620-662 is listed for the 2019 Chevrolet Blazer V6 3.6L, and a single assembly is all that vehicle needs.
Do Dorman fans like this one come with the motor and shroud?
Yes. The box holds one radiator fan assembly, and the motor, shroud, blades, wiring harness and control module are part of it.
Is this Dorman cooling fan assembly brushless?
Yes. Dorman 620-662 has a brushless electric motor rated 12 V DC at 39.9 A, with 11 blades on a 580 mm fan.
What are signs this 11-blade radiator fan may be failing?
A fan that stays still when the engine is hot, a cracked blade or shroud, or a rattle from the fan can mean the assembly is worn. A shop can test the motor's electrical side.
Does this radiator fan replace part number 23412300?
Yes. Dorman 620-662 is listed as a replacement for 23412300, one of the interchange numbers printed on this page.
