Dorman 615-916 upper intake manifold for the 2015-2017 Ford F-150 V8 5.0L and other vehicles replaces the original with stainless steel CMCV shafts. This Dorman OE Solutions intake manifold targets the corrosion that can seize or shear off the original's carbon steel CMCV rods (also called IMRC).
- Stainless steel CMCV shafts for corrosion resistance
- MAP sensor, actuators and fuel hoses can be swapped over from the old manifold
- OE FIX design from the OE Solutions line
- Single-plane design with eight ports
Quick facts
- Part: Dorman 615-916 intake manifold
- Also called: engine intake manifold
- Fits: 2015-2017 Ford F-150 V8 5.0L and other vehicles
- Position: Upper
- Material: Plastic
- Condition: New
A rough idle, backfiring, or overheating with a check engine light can mean a stuck or broken CMCV rod is disabling the manifold air flaps and position sensors. These signs alone do not prove the manifold is the problem, since a faulty ignition coil can also cause a rough idle.
Fits
It is a direct-fit intake manifold for the 2015-2017 Ford F-150 V8 5.0L and the 2015-2017 Ford Lobo V8 5.0L. This listing is one manifold, and either truck takes just one.
Specifications
Fit and size
- Position: Upper
- Quantity per vehicle: 1
- Length: 25 in
- Width: 14.5 in
- Manifold height: 11.2 in
- Port quantity: 8
- Port outlet dimensions: 4 in x 4 in
Build and materials
- Type: Single plane
- Material: Plastic
- CMCV shafts: Stainless steel
- Condition: New
- Country of origin: China
In the box
One intake manifold with one EVAP purge solenoid valve, one MAP sensor O-ring, one fuel injector O-ring, one PCV outlet O-ring, 11 IMRC screws, one MAP sensor screw, one PCV outlet screw, two EVAP solenoid valve screws and installation instructions.
Installation notes
- Installation instructions come with the part.
- Mounting bolts are pre-installed on the manifold.
Interchange: FL3Z9424B · FL3Z9424E · FL3Z9424F · FL3Z9424J
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
FL3Z9424B, FL3Z9424E, FL3Z9424F, FL3Z9424J
Frequently Asked Questions
Does the Dorman 615-916 fit the 2015-2017 Ford Lobo V8 5.0L?
Yes. Dorman 615-916 is listed for the 2015-2017 Ford Lobo V8 5.0L, and that truck takes one manifold.
What screws and O-rings come with this engine intake manifold?
Dorman 615-916 includes 11 IMRC screws, one MAP sensor screw, one PCV outlet screw, two EVAP solenoid valve screws, an EVAP purge solenoid valve, and O-rings for the MAP sensor, fuel injector and PCV outlet.
Are the CMCV shafts on this intake manifold stainless steel?
Yes. The CMCV shafts (also called IMRC) are stainless steel, while the original design used exposed carbon steel rods that can rust and seize.
What can a corroded CMCV rod cause?
A seized or sheared CMCV rod can disable the manifold air flaps and position sensors. A rough idle, backfiring, or overheating with a check engine light can follow.
Can I reuse my MAP sensor and fuel hoses with this manifold?
Yes. The MAP sensor, actuators and fuel hoses can be swapped over from the old manifold. Installation instructions come with the part.
