Dorman 266-024 lower oil pan for the 2014-2021 Jeep Grand Cherokee V6 3.0L holds the engine's oil at the bottom of the engine. This engine oil pan is a complete assembly that includes the drain plug and a gasket or seal.
- Complete assembly with the replacement pan and drain plug
- High-strength coating to resist corrosion
- Aluminum construction with a painted finish
- Wet-sump pan with a center sump location
Quick facts
- Part: Dorman 266-024 oil pan
- Also called: engine oil pan
- Fits: 2014-2021 Jeep Grand Cherokee V6 3.0L
- Position: Lower
- Material: Aluminum
- Condition: New
Oil spots where the vehicle parks, or a cracked or dented pan, can mean the pan needs replacing. Those signs alone do not prove the pan is at fault, because a leaking valve cover gasket can also send oil running down onto it.
Fits
This is a direct-fit replacement oil pan for the 2014-2021 Jeep Grand Cherokee V6 3.0L. The engine takes one pan, fitted under the engine.
Specifications
Fit and size
- Position: Lower
- Quantity per vehicle: 1
- Length: 12.85 in
- Maximum width: 7.5 in
- Depth: 1 in minimum, 3.1 in maximum
- Capacity: 8 U.S. quarts
- Mounting holes: 13
- Drain thread size: 10 mm x 1.25
Build and materials
- Material: Aluminum
- Finish: Painted
- Condition: New
- Country of origin: China
In the box
One oil pan with a drain plug and a gasket or seal. Installation hardware, an oil pickup, a windage tray, a crankshaft wiper and a strap are not included, so plan on new bolts, since the old ones may not be reusable.
Interchange: 68147572AB · 68211182AA · SKP20444
This part cross-references / interchanges with the following part numbers:
68147572AB, 68211182AA, SKP20444
Frequently Asked Questions
Does the Dorman 266-024 oil pan fit the 2014-2021 Jeep Grand Cherokee V6 3.0L?
Yes. Dorman 266-024 is a direct-fit replacement for the 2014-2021 Jeep Grand Cherokee V6 3.0L, and the engine takes one pan.
Does the pan come with its drain plug and gasket?
Yes. Dorman 266-024 comes with the drain plug and a gasket or seal. Installation hardware, an oil pickup, a windage tray, a crankshaft wiper and a strap are not included.
What is the drain plug thread size on this oil pan?
The drain thread size is 10 mm x 1.25. The pan holds 8 U.S. quarts and has 13 mounting holes.
How can I tell if my aluminum oil pan is leaking?
Oil spots where the vehicle parks, or a pan that looks dented or rusted, can be signs of a leak. Inspecting the underside of the engine is a job for a shop.
Can I use Dorman 266-024 in place of part number 68147572AB?
Yes. 68147572AB is one of the numbers this pan replaces, and it is listed on the Interchange line.
