Dorman 521-906 rear right upper control arm with ball joint for the 2006-2015 Suzuki Grand Vitara links the rear right wheel to the vehicle. The Dorman control arm and ball joint assembly is a direct replacement for the original equipment on specific vehicle applications.
- Ball joint and bushings pre-installed on the control arm, which saves time and labor
- Tested to support a smooth ride, directional stability and predictable dynamics
- Steel control arm with rubber bushings
- Additional coatings resist rust and corrosion
Quick facts
- Part: Dorman 521-906 control arm with ball joint
- Also called: control arm and ball joint assembly
- Fits: 2006-2015 Suzuki Grand Vitara
- Position: Rear right upper
- Material: Steel
- Condition: New
A clunk over bumps, uneven tire wear or a loose feel from the rear can mean this arm, its ball joint or its bushings are worn, though a tired shock absorber or a loose sway bar link may be the source instead.
Fits
Dorman 521-906 fits the 2006-2015 Suzuki Grand Vitara, which takes one arm at the rear right upper position. Replacing the rear upper arms together as a pair is the usual practice; this listing is one arm, and the rear left is a separate part.
Specifications
Fit and size
- Position: Rear right upper
- Quantity per vehicle at this position: 1
- Mounting hole diameter: 12.3 mm
- Maximum width: 288.5 mm
- Maximum length: 237 mm
- Ball joint thread diameter: 14 mm
Build and materials
- Control arm type: Casting/Forged
- Control arm material: Steel
- Bushing material: Rubber
- Ball joint stud type: Threaded
- Pre-greased: Yes
- Grade: Standard replacement
- Condition: New
- Country of origin: Taiwan
In the box
One control arm with its ball joint and bushings, plus mounting hardware. A grease fitting is not included.
Interchange: 102-7534
TC7323 · CA10421 · 9CB80278 · RK621732 · CMS801038 · 2606798 · 4620165J00 · 4620165J01
This part cross-references / interchanges with the following part numbers:
102-7534, TC7323, CA10421, 9CB80278, RK621732, CMS801038, 2606798, 4620165J00, 4620165J01
Frequently Asked Questions
Is this the right control arm for the 2006-2015 Suzuki Grand Vitara?
Yes. Dorman 521-906 is the rear right upper control arm with ball joint for the 2006-2015 Suzuki Grand Vitara, and the rear left is a separate part.
Are Dorman control arm bushings included on this arm?
Yes. This arm comes with its rubber bushings and ball joint already installed, and mounting hardware is included. A grease fitting is not.
What kind of ball joint stud does this Dorman upper control arm have?
Dorman 521-906 has a threaded ball joint stud with a 14 mm thread diameter. The mounting hole is 12.3 mm across.
How can I tell if this Dorman OE Solutions control arm is worn?
A clunk over bumps or uneven rear tire wear can mean the arm is worn. A shop can check the bushings and ball joint play, which needs the vehicle raised.
Does Dorman 521-906 replace number 4620165J00?
Yes. 4620165J00 is one of the numbers Dorman 521-906 replaces; the rest are on its Interchange line.
