Gates Engine Coolant Bypass Hose,HVAC Heater Hose,Radiator Coolant Hose P/N:24224

Keep coolant moving where your engine needs it with the Gates Green Stripe 2-Ply Straight Coolant Hose 24224 — a heavy-duty, cut-to-fit hose that serves as an engine coolant bypass hose, HVAC heater hose, or radiator coolant hose. It fits many vehicles, among them the 1987-1993 Ford F-600 6.6L / 7.8L and the 1987-1993 Ford F-700 6.6L / 7.8L — see the Buyer's Guide tab for the full list of applications.

• Two-ply bias-fabric construction: an advanced EPDM tube and cover maximize flexibility and strength, resist "cold water leaks," and stay soft and pliable even under adverse operating conditions.
• Cut-to-fit cover: marked in 1 in. increments to facilitate approximate cut lengths for "custom-fit" installations; 36 in (914 mm) centerline length with a 1.5 in (38 mm) inside diameter at each end.
• Built for demanding service: engineered with compounds that resist electrochemical degradation, exceeds SAE 20R1 Type EC (Class D-1 tube and cover, standard wall), and is approved for marine applications.
• Temperature & pressure: rated from -40°F to +257°F (-40°C to +125°C) with a 100 PSI working pressure.

Use it in upper or lower engine-to-pipe, pipe-to-radiator, outlet, and oil-cooler coolant positions. Caution: do not use for fuel or oil transfer applications. For a maintenance-free connection, use Gates PowerGrip SB clamps. Quantity varies by application — some vehicles use two — and this listing is for one hose. Country of origin: Mexico.

Interchange: 31056 · 596152 · A11887 · 77150 · 77150GL · 8110 · 57024 · 57224 · 66042 · 632 · GPC150
