Four Seasons 77322 A/C compressor for the 1998-2000 Toyota RAV4 is a remanufactured Denso 10PA15L unit that compresses and circulates refrigerant through the A/C system. Every unit is tested so that function and noise level meet or exceed OE specifications.
- Pre-charged with 3 ounces of PAG oil for R134a or R1234yf applications
- Individually vacuum and pressure tested to check for leaks
- R12/R134A/1234yf O-rings and sealing washers included for installation
- Clutch and switch included, with the switch listed as a speed sensor
- Pulley with 5 grooves and a 4.750 in outside diameter, for a serpentine belt
Quick facts
- Part: Four Seasons 77322 A/C compressor
- Fits: 1998-2000 Toyota RAV4
- Condition: Remanufactured
Warm air from the vents, a grinding or squealing noise, or a clutch that does not engage can mean a worn compressor, but they can also come from low refrigerant or an electrical fault. Before replacing it, look over the compressor, its fittings and the belt with the engine off for oily residue or damage, and leave pressure and electrical tests to a shop.
Fits
This is a direct-fit replacement ac compressor for the 1998-2000 Toyota RAV4, which takes one. It may require use of the OE manifold.
Specifications
Fit and size
- Quantity per vehicle: 1
- Mounting type: Tangent mount
- Pulley grooves: 5
- Outside pulley diameter: 4.750 in
- Outlet C length: 121 mm
Build and materials
- Condition: Remanufactured
- Compressor type: Denso 10PA15L
- Refrigerant: R134A
- Compatible oil: PAG 46
- Pulley belt type: Serpentine
- Coil voltage: 12 V DC
- Connector type: Pin
- Country of origin: Mexico
In the box
One remanufactured A/C compressor with the O-rings and sealing washers needed to install it, including one compressor manifold gasket (24156). Mounting hardware is not included, so plan on new bolts rather than reusing old ones.
Frequently Asked Questions
Is this the right ac compressor replacement for the 1998-2000 Toyota RAV4?
Yes. Four Seasons 77322 is a direct-fit replacement for the 1998-2000 Toyota RAV4, which takes one.
Do I need to buy O-rings separately for Four Seasons 77322?
No. Four Seasons 77322 includes the O-rings and sealing washers needed to install it. Mounting hardware is not included, so plan on new bolts.
Is this Four Seasons compressor pre-charged with oil, and which refrigerant does it suit?
Yes. This compressor comes with 3 ounces of PAG oil, rated for R134a or R1234yf applications. The catalog lists R134A refrigerant and PAG 46 as the compatible oil.
How is this remanufactured A/C compressor tested?
Each unit is 100 percent tested for compressor function and noise level, and individually vacuum and pressure tested to make sure it does not leak.
Is the clutch included with this A/C compressor?
Yes. The clutch is included, with a 12-volt DC coil, along with a switch listed as a speed sensor.
