Four Seasons 66142 A/C suction and liquid line hose assembly for the 2014-2016 Land Rover LR4 V6 3.0L routes refrigerant between the A/C components. It is an internal heat exchange (IHX) hose assembly for the suction and liquid lines.
- Double wall barrier hose construction
- Crimp fitting connection
- P-Nut fittings on both ends
- Aluminum material
- Application-specific design
Quick facts
- Part: Four Seasons 66142 A/C suction and liquid line hose assembly
- Also called: A/C suction line
- Fits: 2014-2016 Land Rover LR4 V6 3.0L
- Material: Aluminum
- Condition: New
Weak cooling, or oily residue at a crimped fitting, can mean this hose assembly has a leak. A leaking condenser or a worn compressor can also be behind weak cooling, so find the cause before replacing the hose assembly.
Fits
It fits the 2014-2016 Land Rover LR4 V6 3.0L.
Specifications
Fit and size
- Quantity per vehicle: 1
- End types: P-Nut fitting on both ends
Build and materials
- Style: hose assembly with IHX
- Material: Aluminum
- Refrigerant type: R134A, R1234YF
- Condition: New
- Country of origin: China
In the box
One hose assembly with fittings and four o-rings (two 24611 and two 24150). A service port, bracket and muffler are not included. This listing holds one assembly, and the 2014-2016 Land Rover LR4 V6 3.0L takes one.
Interchange: 211040 · A82641 · LR050913
This part cross-references / interchanges with the following part numbers:
66142, 211040, A82641, LR050913
Frequently Asked Questions
Does the Four Seasons 66142 hose assembly fit a 2014-2016 Land Rover LR4 V6 3.0L?
Yes. Four Seasons 66142 is listed for the 2014-2016 Land Rover LR4 V6 3.0L, and that vehicle takes one assembly.
Do the o-rings and fittings come with this IHX hose assembly?
Yes. The assembly comes with fittings and four o-rings, two 24611 and two 24150. A bracket, muffler and service port are not included.
Is this A/C suction line compatible with R1234YF refrigerant?
Yes. Its double wall barrier hose is compatible with R1234YF and R134A refrigerant.
How can I tell if the fittings on this hose assembly are leaking?
Oily residue around a crimped fitting or weak cooling can point to a leak. Look only with the engine off, and have a shop test the A/C system, since its lines are under pressure.
Does Four Seasons 66142 replace LR050913?
Yes. LR050913 is one of the numbers Four Seasons 66142 replaces, along with 211040 and A82641.
