Four Seasons 76528 front blower motor for the 2017-2024 Nissan Armada and other vehicles drives a wheel that pushes air through the heater and A/C vents. Its magnet size, magnetic properties and motor RPM compare to or exceed the OEM motor.
- Brushless motor in a flanged, vented housing
- Hermetically sealed, thermally protected electronics
- Cage wheel included with the motor
- Clockwise (CW) rotation on 12 volts
Quick facts
- Part: Four Seasons 76528 blower motor
- Also called: HVAC blower motor
- Fits: 2017-2024 Nissan Armada and other vehicles
- Position: Front
- Material: Plastic
- Condition: New
Weak airflow, a whirring or squealing noise from the dash, or no air at all can mean the blower motor is wearing out. Before you replace it, rule out a blown fuse, a worn blower resistor or a loose connector, since any of them can also cut airflow.
Fits
It is a blower motor for the 2017-2024 Nissan Armada, the 2014-2024 Infiniti QX80 and the 2011-2013 Infiniti QX56, with one motor per vehicle. It is built to meet or exceed O.E. design and performance.
Specifications
Fit and size
- Position: Front
- Quantity per vehicle: 1
- Wheel diameter: 6.375 in
- Rotation: clockwise (CW)
- Voltage: 12 volts
- Connector: female, 6 terminals, 2 Spade 4 Pin, 1 connector
Build and materials
- Type: brushless, flanged, vented
- Material: Plastic
- Cage wheel: included
- Condition: New
- Country of origin: Canada
In the box
One blower motor with its cage wheel.
Interchange: 6553426 · 27220JK00A · 27220JK00C · 27220JK00D · 27220JK01A · PM5137 · 2312024 · A58528 · 871198 · 700355 · BM5137C
This part cross-references / interchanges with the following part numbers:
6553426, 76528, 27220JK00A, 27220JK00C, 27220JK00D, 27220JK01A, PM5137, 2312024, A58528, 871198, 700355, BM5137C
Frequently Asked Questions
Does the Four Seasons 76528 blower motor fit the 2017-2024 Nissan Armada?
Yes. Four Seasons 76528 is listed for the 2017-2024 Nissan Armada, and each vehicle takes one.
Does this Four Seasons blower motor come with the wheel?
Yes. The Four Seasons 76528 listing is one blower motor with its cage wheel, which has a diameter of 6.375 in.
Is this Four Seasons HVAC blower motor brushless?
Yes. It is a brushless, flanged and vented motor that turns clockwise (CW) and runs on 12 volts.
Could weak airflow from the vents mean the blower motor is failing?
It can. Weak airflow, a whirring or squealing noise from the dash, or no air at all can mean this blower motor is wearing out. A shop can test the motor to confirm.
What connector does the 76528 blower motor use?
Four Seasons 76528 has one female connector with 6 terminals, listed as a 2 Spade 4 Pin type.
