Gates 29G3596 CVT belt for the 2016-2025 Yamaha YFM700K Kodiak and other vehicles transfers engine power between the CVT drive pulleys. Also called a cvt transmission belt, it is engineered for the toughest tasks and trails and gives up to 2x the life of the original G-Force belt.
- G-Force WorkHorse line, optimized for engines of less than 800cc
- Improved durability with crack and wear resistance
- Proprietary Ethylene Elastomer (EE) compound for axial stiffness and heat tolerance, with less heat fade and less speed loss
- High tensile aramid cord for acceleration, shock load resistance and fatigue resistance when hauling heavy loads over aggressive terrain
- Not for use in turbocharged or heavily modified engine applications
Quick facts
- Part: Gates 29G3596 CVT belt
- Also called: cvt transmission belt
- Fits: 2016-2025 Yamaha YFM700K Kodiak and other vehicles
- Position: Drive belt
- Material: Ethylene Elastomer belt with Aramid cord
- Condition: New
Cracks, fraying or glazed sides on the belt, or slipping and lost speed while riding, can mean it is worn. Those symptoms can also start elsewhere in the CVT drive, so with the engine off and cool, look the belt over and measure its top width against 33 mm before you buy a new one.
Fits
This CVT belt is a direct-fit replacement for the 2016-2025 Yamaha YFM700K Kodiak EPS, the 2018-2027 Yamaha YFM700 Grizzly EPS and other vehicles. The 2016-2025 Yamaha YFM700K Kodiak takes one belt. Open the "Vehicles it fits" section to check your exact model and engine.
Specifications
Fit and size
- Position: drive belt
- Quantity per vehicle: 1
- Top width: 33 mm (1.281 in)
- Outside circumference: 943 mm (37.125 in)
- Cross section designation: RVS-R
Build and materials
- Type: power sport CVT belt
- Construction: double notched
- Belt material: ethylene elastomer
- Cord material: aramid
- Condition: new
- Country of origin: United States
Interchange: 72-4003
UA461 · 29C3596 · HP2033 · HPX2233 · XTX2233 · XTX2241 · XTX2271 · DBWH5B4 · DBYA5B4EX · 33GBS943 · UA422 · UHQ422 · UXP422
This part cross-references / interchanges with the following part numbers:
UA461, 29C3596, 29G3596, HP2033, HPX2233, XTX2233, XTX2241, XTX2271, DBWH5B4, DBYA5B4EX, 33GBS943, 72-4003, UA422, UHQ422, UXP422
Frequently Asked Questions
Does the Gates 29G3596 CVT belt fit the 2018-2027 Yamaha YFM700 Grizzly EPS?
Yes. Gates 29G3596 fits the 2018-2027 Yamaha YFM700 Grizzly EPS. Open the "Vehicles it fits" section to check other models and engines.
How wide is the Gates 29G3596 belt?
Gates 29G3596 has a top width of 33 mm (1.281 in) and an outside circumference of 943 mm (37.125 in). Its cross section designation is RVS-R, and it is double notched.
What is this CVT belt made of?
The belt is made of Ethylene Elastomer with an aramid cord. The high tensile aramid cord is for acceleration, shock load resistance and fatigue resistance.
Can this WorkHorse belt go on a turbocharged or heavily modified engine?
No. This belt is not for turbocharged or heavily modified engine applications. It is optimized for engines of less than 800cc.
What signs can show a G-Force WorkHorse belt is worn?
With the engine off and cool, cracks, fraying or glazed sides can show wear, and slipping or lost speed while riding can too. A shop can test the rest of the CVT drive.
