Gates Engine Coolant Bypass Hose,HVAC Heater Hose,Radiator Coolant Hose P/N:24216

Keep coolant moving through demanding heavy-duty cooling systems with the Gates Green Stripe 2-Ply Straight Coolant Hose, MPN 24216. This 36-inch (914 mm) straight length with a 1-inch (25 mm) inside diameter at each end serves as a bypass, HVAC heater, and radiator coolant hose across a wide range of positions — engine-to-pipe (upper and lower), heater inlet, radiator-to-pipe, reservoir-to-radiator, outlet, coolant reservoir, oil cooler, and filler tank. It fits a broad list of heavy-duty applications, including the 1989-1997 Ford L9000 [6-10.5L], 1981-1988 GMC General [L6-14.6L], and 1991-1993 International 2554 [L6-7.6L] — see the Buyer's Guide tab for the full list.

• 2-Ply bias-fabric EPDM construction: the two-ply bias weave maximizes flexibility and strength, with an EPDM tube and cover that resist "cold water leaks" and stay soft and pliable even under adverse operating conditions.
• Cut-to-fit cover: marked in 1-inch increments to make approximate cut lengths easy for custom-fit installations.
• Built to spec: exceeds SAE 20R1 Type EC (Class D-1 tube and cover, standard wall), rated to 100 PSI working pressure and a temperature range of -40°F to +257°F (-40°C to +125°C).
• Extra protection: engineered with compounds that resist electrochemical degradation, and approved for marine applications.

Caution: do not use for fuel or oil transfer applications. For a maintenance-free connection, Gates recommends PowerGrip SB clamps. Country of origin: Mexico.

Interchange: 31052 · 3930828 · 77100 · 77100GL · 8103 · 57016 · 57216 · L2643493 · R501102 · 628 · GPC100
