Gates 34822 thermostat for the 2006-2008 Volkswagen Passat V6 3.6L and other vehicles opens and closes with coolant temperature to regulate engine operating temperature. Also known as an engine coolant thermostat, this Gates thermostat has OEM fit, function and design for precise engine cooling.
- Gates OE Type thermostat line
- Reverse poppet design
- Jiggle pin with a weep hole and one check valve for air venting
- Starts to open at 176°F (80°C)
- Quality-controlled factory calibration keeps opening and closing accurate despite pressure changes
Quick facts
- Part: Gates 34822 thermostat
- Also called: engine coolant thermostat
- Fits: 2006-2008 Volkswagen Passat V6 3.6L and other vehicles
- Material: Steel, Copper, Plastic
- Condition: New
A temperature gauge that runs hot or stays low can mean a thermostat is sticking open or closed. Because low coolant or a leak can also move the gauge, check the level with the engine cool and look over the hoses and housing for leaks before replacing the thermostat.
Fits
It is also a thermostat for the 2007-2010 Audi Q7 V6 3.6L and the 2007-2010 Volkswagen Touareg V6 3.6L, with one thermostat going in each engine. If your car is not one of these, enter its year, model and engine in the "Vehicles it fits" section to see whether it takes this thermostat.
Specifications
Fit and size
- Quantity per vehicle: 1
- Height: 2.86 in
- Height between flanges: 2.21 in
- Flange height: 0.65 in
- Sealing flange outside diameter: 1.63 in
- Start to open temperature: 176°F (80°C)
Build and materials
- Type: OE Type thermostat, OE Performance grade
- Design: reverse poppet
- Material: steel, copper, plastic
- Jiggle pin: with weep hole, 1 check valve
- Condition: New
- Country of origin: China
In the box
One thermostat. No gasket, seal or installation tool is included.
Interchange: 733-176
95510612600 · 03H121113
This part cross-references / interchanges with the following part numbers:
733-176, 34822, 95510612600, 03H121113
Frequently Asked Questions
Is Gates 34822 the VW Passat thermostat for the 2006-2008 Volkswagen Passat V6 3.6L?
Yes. Gates 34822 fits the 2006-2008 Volkswagen Passat V6 3.6L, one per engine. For another car, look up its year and engine in the "Vehicles it fits" section.
Does the Gates 34822 thermostat come with a gasket or seal?
No. This listing is one thermostat. Its gasket quantity and seal quantity are both 0, and no installation tool is included.
At what temperature does this thermostat start to open?
Gates 34822 starts to open at 176°F (80°C). Its factory calibration is quality-controlled so opening and closing stay accurate when pressure changes.
What is the jiggle pin on this thermostat for?
The jiggle pin vents air from the cooling system. This thermostat has a weep hole in the pin and one check valve.
Does Gates 34822 replace thermostat number 733-176?
Yes. 733-176 is one of the numbers listed on the Interchange line, along with 95510612600 and 03H121113.
