Four Seasons 73348 mode door actuator for the 1996-2019 GMC Savana 2500 and other vehicles is the motor-driven unit that moves the mode door inside the HVAC housing to send air to the vents you select.
- Engineered and tested for years of trouble free operation, backed by over 50 years of mobile A/C experience.
- Meets or exceeds OE specifications for fit and function.
- Quality internal motor, drive gears, electronics and connections.
- Tested for function, durability and longevity.
A worn actuator can show up as air that stays at one outlet, a clicking from behind the dash or a mode selector that no longer changes outlets. Before you replace it, rule out a damaged connector, a blown fuse and a door that binds in the housing, since a fault in any of them can leave the controls unresponsive.
This actuator is listed for a wide range of Chevrolet and GMC models, including the 1996-2019 GMC Savana 3500 and the 1996-2024 Chevrolet Express 2500. If your vehicle is not one of these, enter its year, model and engine on the Buyer's Guide tab to see where it is listed.
Specifications
In the box
Lever arm, gear, cam gear hardware and linkage, as applicable.
Interchange: 1572250 · 1574934 · 604922 · BDAE1314 · 01996836 · 1996836 · 89019069 · 8019968360 · 2388 · DA1340 · 65519141 · A60348 · MT7407 · 100231
This part cross-references / interchanges with the following part numbers:
1572250, 1574934, 73348, 604922, BDAE1314, 01996836, 1996836, 89019069, 8019968360, 2388, DA1340, 65519141, A60348, MT7407, 100231
