KYB 565033 rear shock absorber for the 1988-1999 Chevrolet C1500 and other vehicles is a high-pressure monotube gas shock for trucks. Its large-bore design adds stability for heavier, more powerful or high center of gravity vehicles that tow, haul or go off-road.
- KYB MonoMax large-bore monotube gas design made only for trucks
- Zinc-coated piston ring that gives a positive seal in extreme conditions
- Rubber boot protects the shaft and keeps dirt and debris away from the seals
- Internal rebound bumper
- Engineered to help vehicles with electronic safety systems such as ESC and ABS
Quick facts
- Part: KYB 565033 shock absorber
- Fits: 1988-1999 Chevrolet C1500 and other vehicles
- Position: Rear
- Condition: New
Oil film on the shock body, a clunk over bumps or a floaty, bouncing rear end can mean the shock is worn. Worn bushings, springs or rear mounts can be behind the same signs, so find the cause before buying.
Fits
The 1988-1999 Chevrolet C1500, 1995-1999 Chevrolet Tahoe and 1995-1999 GMC Yukon take this shock, and so do many more GM trucks and vans. If your truck or van is not named here, look up your own year and model in the "Vehicles it fits" section. This listing is one shock; the other side of the rear axle is normally done at the same time, and the axle takes two, one on each side.
Specifications
Fit and size
- Position: Rear
- Quantity per vehicle: 2
- Extended length: 22.36 in
- Compressed length: 14.41 in
- Stroke length: 7.95 in
- Upper mount type: E3(61.6x87x0)
- Lower mount type: E2(14.6x41)
Build and materials
- Type: high-pressure monotube gas shock
- Dust boot: included
- Internal rebound bumper: yes
- Condition: New
- Country of origin: Mexico
In the box
One rear shock absorber with an off-road dust boot. A bump stop is not included.
Interchange: 77638 · 911085
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Does the KYB 565033 fit a 1995-1999 GMC Yukon?
Yes. The KYB 565033 rear shock absorber is listed for the 1995-1999 GMC Yukon, and the rear axle takes two, one on each side.
Does this KYB shock absorber come with a dust boot?
Yes. The KYB 565033 includes an off-road dust boot, a rubber boot that protects the shaft and keeps dirt and debris away from the seals. A bump stop is not included.
Is the KYB 565033 a KYB gas a just shock absorber?
No. KYB 565033 is a KYB MonoMax, a high-pressure monotube gas shock made for trucks.
How can I tell if the gas shocks on my rear axle are wearing out?
Look for oil film on the shock body, a torn boot or a bouncy, floaty ride. A shop can test the shock to confirm.
Is the KYB gas shock absorber 565033 a monotube design?
Yes. KYB 565033 is a high-pressure monotube gas shock from the KYB MonoMax truck line, with a zinc-coated piston ring.
