Mevotech Supreme CMS601180 rear upper lateral link and ball joint assembly for the 2006-2014 Honda Ridgeline holds the rear wheel in position in the suspension. The ball joint pivots as the suspension moves up and down.
- Protective surface treatment to resist rust build-up
- Adjustable link with a camber adjustment range of ±2.0°
- Unitized ball joint mounting with a threaded stud
- Rubber bushings included with the assembly
- Additional hardware included in the box to simplify installation
Quick facts
- Part: Mevotech Supreme CMS601180 lateral link and ball joint assembly
- Fits: 2006-2014 Honda Ridgeline
- Position: Rear upper
- Material: Steel
- Condition: New
A clunk from the rear over bumps, uneven rear tire wear or an alignment that will not hold camber can point to a worn link or ball joint. Before you replace this assembly, rule out other rear suspension wear, such as tired shocks or loose links, that could produce similar noises.
Fits
It fits the 2006-2014 Honda Ridgeline, which takes two. This listing is one assembly, and both sides are normally replaced together.
Specifications
Fit and size
- Position: Rear upper
- Quantity per vehicle: 2
- Length: 10.65 in
- Camber adjustment range: ±2.0°
Build and materials
- Material: Steel
- Ball joint mounting type: Unitized
- Stud type: Threaded
- Bushing material: Rubber
- Condition: New
- Country of origin: United States
In the box
One lateral link and ball joint assembly with rubber bushings, plus a castle nut and a cotter pin.
Installation notes
- The ball joint comes pre-greased.
- The extra hardware in the box is there to simplify installation.
Interchange: 522-437
19340620 · TC6946 · CB59626 · CB59626PR · CA4669 · 2CB60333 · RK621807 · GS601180 · 2643101 · 30030204 · TK621807
This part cross-references / interchanges with the following part numbers:
19340620, TC6946, 522-437, CB59626, CB59626PR, CA4669, 2CB60333, RK621807, GS601180, CMS601180, 2643101, 30030204, TK621807
Frequently Asked Questions
Does the Mevotech Supreme CMS601180 fit the 2006-2014 Honda Ridgeline?
Yes. Mevotech Supreme CMS601180 is a rear upper lateral link and ball joint assembly for the 2006-2014 Honda Ridgeline, which takes two.
Do the castle nut and cotter pin come with this lateral link assembly?
Yes. The box holds the assembly with its rubber bushings, plus a castle nut and a cotter pin.
How much camber adjustment does this rear upper lateral link give?
The camber adjustment range is ±2.0°. The assembly is listed as adjustable.
How can I tell if the ball joint on a rear upper lateral link is worn?
A clunk from the rear over bumps, uneven rear tire wear or an alignment that will not hold can point to wear here, though other suspension parts can cause them too. A shop can test the joint.
Is the ball joint on Mevotech Supreme CMS601180 pre-greased?
Yes. The ball joint on this Mevotech Supreme CMS601180 assembly comes pre-greased, and a castle nut and cotter pin are in the box.
