MOOG Chassis CK7424 front upper control arm with ball joint for the 2002-2005 Dodge Ram 1500 and other vehicles joins the steering knuckle to the frame. This control arm and ball joint assembly includes the bushings, ball joint and grease fitting, and it comes pre-greased.
- MOOG High Utilization Design for heavier loads and more punishing roads
- Problem Solver Gusher Bearing: metal-to-metal design lets grease flow through the bearing surface for reduced friction and long life
- Greaseable socket lets new lubricant flush out contaminants, reducing corrosion and wear
- Pre-installed dust boot shields the socket components from wear-causing contaminants
- Belleville preload washer helps keep the bearing package tight as the bearings wear
- Pre-installed bushings with optimized stiffness inhibit noise
Quick facts
- Part: MOOG Chassis CK7424 control arm with ball joint
- Also called: control arm and ball joint assembly
- Fits: 2002-2005 Dodge Ram 1500 and other vehicles
- Position: Front upper
- Material: Forged steel control arm, rubber bushings
- Condition: New
A worn upper arm or ball joint can show up as a clunk over bumps, loose or wandering steering, or uneven tire wear. A worn tie rod end can also loosen the steering, so these signs alone do not prove this arm is the problem.
Fits
It fits the 2002-2005 Dodge Ram 1500, the 2004-2009 Dodge Durango and the 2007-2009 Chrysler Aspen. This listing is one front upper arm; the front axle takes two, one per side, and the other side is normally replaced at the same time.
Specifications
Fit and size
- Position: Front upper
- Quantity per vehicle: 2
- Control arm maximum length: 13.74 in
- Ball joint mounting type: Bolt in
- Ball joint stud type: Threaded
- Adjustable: No
Build and materials
- Control arm material: Forged steel
- Bushing material: Rubber
- Pre-greased: Yes
- Condition: New
- Country of origin: United States
In the box
One control arm with the ball joint, bushings, grease fitting and mounting hardware.
Frequently Asked Questions
Is this the upper control arm for a 2002-2005 Dodge Ram 1500?
Yes. MOOG Chassis CK7424 is a front upper control arm with ball joint for the 2002-2005 Dodge Ram 1500, and the front axle takes two, one per side.
Are these 2002-2005 Dodge Ram 1500 control arms also right for the 2004-2009 Dodge Durango?
Yes. The MOOG Chassis CK7424 front upper arm also fits the 2004-2009 Dodge Durango and the 2007-2009 Chrysler Aspen.
What is the MOOG CK7424 control arm made of?
The control arm is forged steel, and the pre-installed bushings are rubber.
Does this front upper control arm come with the ball joint and bushings already in it?
Yes. It includes the ball joint, bushings, grease fitting and mounting hardware, and the bushings and dust boot are pre-installed.
Can the ball joint socket on this front upper arm be greased?
Yes. The socket is greaseable, so new lubricant can flush out contaminants, and the arm comes pre-greased with a grease fitting included.
