MOOG Chassis Products RK100092 front upper control arm with ball joint for the 1998-2005 Volkswagen Passat and other vehicles connects the front suspension to the wheel and lets it move and steer.
- Forged steel control arm built for structural strength and corrosion protection
- Precision tolerances for installation and steering alignment
- Rubber bushings optimized for quiet operation and resistance to wear, salt, road grime and oils
- Ball joint pre-installed with a sealed socket for maintenance-free operation
- Heat treated to inhibit premature failure
- E-coated control arm and coated studs to inhibit premature deterioration
Quick facts
- Part: MOOG Chassis Products RK100092 control arm with ball joint
- Also called: control arm and ball joint assembly
- Fits: 1998-2005 Volkswagen Passat and other vehicles
- Position: Front upper
- Material: Forged steel
- Condition: New
A clunk over bumps, uneven front tire wear or loose steering can mean a worn arm, bushing or ball joint. These signs alone do not prove this part is the problem, since a worn tie rod end can give a similar feel. Arms are normally replaced as a pair, and this listing is one; the car takes two, one on each side of the front axle.
Fits
This control arm and ball joint assembly is a direct-fit replacement for the 1998-2005 Volkswagen Passat, the 2004-2009 Audi S4 and the 1998-2009 Audi A4, among other Audi and Volkswagen models. If your car is not named here, find it in the "Vehicles it fits" section on this page.
Specifications
Fit and size
- Position: Front upper
- Quantity per vehicle: 2
- Ball joint mounting type: Press in
- Ball joint stud type: Pinch
Build and materials
- Type: Control arm with ball joint
- Control arm material: Forged steel
- Bushing material: Rubber, bushings included
- Ball joint: Included, pre-installed
- Condition: New
- Country of origin: United States
In the box
One control arm with its bushings and pre-installed ball joint. A grease fitting is not included.
Frequently Asked Questions
Is this VW Passat control arm the right one for 1998-2005 cars?
Yes. MOOG Chassis Products RK100092 is a front upper control arm with ball joint for the 1998-2005 Volkswagen Passat. Look up other cars in the "Vehicles it fits" section.
Will the 2004-2009 Audi S4 take this front upper arm?
Yes. MOOG RK100092 fits the 2004-2009 Audi S4 in the front upper position, and the car takes two, one on each side of the axle.
Does this MOOG arm come with bushings and a ball joint?
Yes. The bushings are included and the ball joint is pre-installed in the arm. A grease fitting is not included.
What is the control arm made of, and what type of bushings does it have?
The control arm is forged steel and the bushings are rubber. The ball joint is a press-in type with a pinch stud.
Does the ball joint on this arm need greasing?
No. The ball joint is pre-installed with a sealed socket for maintenance-free operation, and no grease fitting is included.
