MOOG 512514 rear wheel bearing and hub assembly for the 2014-2022 Jeep Cherokee and other vehicles carries the rear wheel on a bearing so it turns freely on the axle.
- Design enhancements aimed at longer product life and simpler installation and replacement
- Roll form design for consistent and optimal preload
- Bearing raceways and rolling elements matched through tightly controlled manufacturing to minimize noise and vibration
- Hub assembly performance proven and quality tested
Quick facts
- Part: MOOG 512514 wheel bearing and hub assembly
- Fits: the 2014-2022 Jeep Cherokee and other vehicles
- Position: Rear
- Condition: New
A worn rear wheel bearing can show up as a humming or growling noise that changes with speed, vibration, or looseness at the wheel. Tires, brakes and other parts can cause similar signs, so look the rear wheel and brake area over for visible damage first, with the engine off.
Fits
It fits the 2014-2022 Jeep Cherokee and the 2015-2017 Chrysler 200. This listing is one wheel bearing and hub assembly, and the other side of the same rear axle is normally done at the same time.
Specifications
Fit and size
- Position: Rear
- Quantity per vehicle: 2
- Bolt circle diameter: 110 mm (4.33 in), 4 flange bolt holes
- Brake pilot diameter: 69.9 mm
- Flange diameter: 130.2 mm
- Flange offset: 48.6 mm
- Flange shape: rectangle
Build and materials
- Type: wheel bearing and hub assembly
- ABS sensor: not included
- Condition: New
- Country of origin: Taiwan
In the box
One wheel bearing and hub assembly; the ABS sensor is not included. The 2014-2022 Jeep Cherokee and the 2015-2017 Chrysler 200 take two, one for each side of the rear axle.
Interchange: WE61828 · 68155868AB · 68155868AA · MB25314 · BR930609 · HA590552 · HA590599
This part cross-references / interchanges with the following part numbers:
WE61828, 68155868AB, 68155868AA, MB25314, BR930609, HA590552, HA590599
Frequently Asked Questions
Will this 2014-2022 Jeep Cherokee wheel bearing fit the rear axle?
Yes. MOOG 512514 is a rear wheel bearing and hub assembly listed for the 2014-2022 Jeep Cherokee.
Does the 2015-2017 Chrysler 200 wheel bearing from MOOG come with the hub?
Yes. MOOG 512514 is a rear wheel bearing and hub assembly in one unit, listed for the 2015-2017 Chrysler 200.
Does MOOG 512514 come with the ABS sensor?
No. The ABS sensor is not included. This listing is one hub assembly, and the car takes two, one per rear wheel.
What are the bolt circle and pilot sizes of this rear hub assembly?
The bolt circle diameter is 110 mm (4.33 in) with 4 flange bolt holes, and the brake pilot diameter is 69.9 mm. The flange is 130.2 mm across.
What can a worn rear wheel bearing and hub assembly sound like?
A humming or growling noise that changes with speed, vibration or looseness at the wheel can mean a worn bearing. Tires and brakes can cause similar signs, so a shop can confirm it.
