NGK 8017 spark plug wire set for the 1985-1987 Honda Civic 4-cylinder 1.5L carries high voltage from the coil to the spark plugs. Every NGK wire is built to OEM tolerances, and the set has four wires, including the coil lead.
- Outer jacket withstands temperatures greater than 250 degrees C
- Inner insulation of EPDM or silicone for dielectric strength
- Stainless steel terminals with up to 3 serrated crimps for terminal retention
- Locking C-shaped spring clip with corrosion-resistant plating at the spark plug terminal
- Variable pitch winding over a ferrite magnetic alloy coating for low resistance and EMI/RFI noise suppression
- Spark plug boots glued to the cable with silicone sealer for a watertight seal
Quick facts
- Part: NGK 8017 spark plug wire set
- Fits: 1985-1987 Honda Civic 4-cylinder 1.5L
- Condition: New
Engine misfires, hard starting or a cracked or burned boot can mean the wire set is worn, though old spark plugs or a failing ignition coil can sit behind the same symptoms, so find the cause before replacing anything.
Fits
This NGK wire set is a direct-fit replacement for the 1985-1987 Honda Civic 4-cylinder 1.5L, which takes one set.
Specifications
Fit and size
- Quantity per vehicle: 1 set
- Wires: 4, including the coil lead
Build and materials
- Construction: variable pitch magnetic core
- Terminals: stainless steel
- Outer jacket: EPDM/silicone
- Condition: New
- Warranty: NGK limited lifetime warranty, see package for details
- NGK part number: RC-HE40
Installation notes
- Cylinder lead identification tags, where possible, make installation easier.
Interchange: 175-5809 · 35-4216 · 671-4185 · RC-HE40
86451 · 96451 · CH7457 · CH7486 · 700799 · 09407 · 9407 · 12464 · 127486 · 164013 · 55029 · 55030 · 7470 · 9499
This part cross-references / interchanges with the following part numbers:
RC-HE40, 86451, 96451, CH7457, CH7486, 175-5809, 700799, 09407, 9407, 35-4216, 671-4185, 8017, 12464, 127486, 164013, 55029, 55030, 7470, 9499
Frequently Asked Questions
Are NGK plug wires 8017 right for the 1985-1987 Honda Civic 4-cylinder 1.5L?
Yes. NGK 8017 is listed for the 1985-1987 Honda Civic 4-cylinder 1.5L, and that engine takes one set.
What do NGK spark plug wire sets like the 8017 use for terminals?
Stainless steel terminals with up to 3 serrated crimps that bite into the cable jacket and inner insulation, wherever possible, to hold the wire in place.
How much heat can the jacket on this plug wire set take?
The outer jacket of the NGK 8017 set is built to withstand temperatures greater than 250 degrees C, and the inner insulation is EPDM or silicone.
Is RC-HE40 the same set as 8017?
Yes. This set is catalogued under both 8017 and RC-HE40, so searching either number finds it.
Is the winding in these NGK blue spark plug wires meant to cut radio interference?
Yes. The variable pitch winding over a ferrite magnetic alloy coating is designed to suppress EMI/RFI noise while keeping resistance low.
