NGK 8034 spark plug wire set for the 1992-1995 Honda Civic 4-cylinder 1.5L, the 1992-2000 Civic 4-cylinder 1.6L and other vehicles carries high voltage from the ignition system to the spark plugs.
- Variable pitch resistor cable gives uniform resistance and strong electrical conductivity
- Outer jacket withstands temperatures above 250 degrees C, and the inner EPDM or silicone insulation holds in high voltage
- Variable pitch winding over a ferrite magnetic alloy coating gives low resistance and suppresses EMI/RFI noise
- Stainless steel terminals with up to 3 serrated crimps grip the cable jacket and inner insulation
- Silicone sealer glues the plug boots to the cable for a watertight seal
- Cylinder lead identification tags, where possible, make installation easier
Quick facts
- Part: NGK 8034 spark plug wire set
- Fits: the 1992-1995 Honda Civic 4-cylinder 1.5L, the 1992-2000 Civic 4-cylinder 1.6L and other vehicles
- Condition: New
Misfires, a rough idle, hard starting or cracked, burned boots can point to worn plug wires. These signs alone do not prove the wires are at fault, since a worn spark plug is another common source of misfires. The 1992-1995 Honda Civic 4-cylinder 1.5L takes one NGK wire set with four wires.
Fits
This set is a direct-fit replacement for the 1992-1995 Honda Civic 4-cylinder 1.5L, the 1992-2000 Civic 4-cylinder 1.6L, the 1997-2000 Acura EL 4-cylinder 1.6L and the 1993-1995 Honda Civic Del Sol 4-cylinder 1.6L.
Specifications
Fit and size
- Pieces in set: 4 wires
- Quantity per vehicle: 1 set
- NGK part number: RC-HE76
Build and materials
- Construction: variable pitch resistor cable
- Terminals: stainless steel
- Plug terminal clip: locking C-shaped spring clip with corrosion-resistant plating
- Condition: New
- Warranty: NGK limited lifetime warranty, see package for details
Interchange: 175-5957 · 175-6025 · 175-6066 · 175-6145 · 35-4214 · 671-4179 · 671-4183 · 35-PF77554 · 35-PF77569 · RC-HE76
86535 · 86820 · CH74122 · CH74148 · 700532 · 09818 · 09819 · 09828 · 9818 · 9819 · 9828 · 1274122 · 1274148 · 164011 · 55001 · 7468
This part cross-references / interchanges with the following part numbers:
RC-HE76, 86535, 86820, CH74122, CH74148, 175-5957, 175-6025, 175-6066, 175-6145, 700532, 09818, 09819, 09828, 9818, 9819, 9828, 35-4214, 671-4179, 671-4183, 8034, 1274122, 1274148, 35-PF77554, 35-PF77569, 164011, 55001, 7468
